Foxboro P0924JH Terminal Assembly for FBM214b & FBM216b HART Analog Input Modules (I/A Series DCS)

Product Description

The Foxboro P0924JH is a factory-matched terminal assembly engineered exclusively for the FBM214b (8-channel non-redundant HART communication input) and FBM216b (8-channel redundant HART communication input) modules in the Foxboro I/A Series DCS platform. Designed to provide safe, reliable field wiring termination, loop power distribution, and signal protection for 4-20mA HART-enabled analog input channels, this rugged terminal assembly features isolated terminal blocks, surge/transient protection, and a compact rack-mount form factor compatible with 100 Series Fieldbus Module Upgrade subsystems. With industrial-grade EMI/RFI shielding, IP20 front-panel protection, wide temperature operation (-40°C to +70°C), and hot-swap compatible wiring design for minimal downtime, it is certified for critical process control applications in power generation, chemical processing, oil & gas, and manufacturing industries, ensuring seamless integration and stable signal transmission for HART intelligent field devices.

Key Functions

The P0924JH terminal assembly delivers mission-critical wiring termination and signal protection for FBM214b/FBM216b HART input modules with these core features: Dedicated 8-channel terminal blocks for 4-20mA HART analog input signals (compatible with both non-redundant FBM214b and redundant FBM216b I/O modules); Isolated loop power distribution (24 VDC ±10%) to each HART channel with overcurrent/short-circuit protection; Surge/transient voltage suppression for field wiring to protect module electronics; EMI/RFI shielding to prevent signal interference in harsh industrial environments; Hot-swap compatible wiring design allowing module replacement without rewiring; Compact rack-mount form factor for seamless integration into Foxboro I/A Series DCS cabinets; Compliance with IEC 61010 safety standards and HART physical layer specifications for reliable communication with intelligent field devices.

Application Scenarios

The Foxboro P0924JH terminal assembly is optimized for critical process control applications requiring reliable HART-enabled analog input signal termination, including: Upstream/midstream oil & gas production with HART pressure, flow, and level transmitters; Chemical processing plants with redundant safety instrumented systems (SIS) and HART analytical instruments; Power generation facilities with turbine/boiler control systems and HART temperature/pressure sensors; Pharmaceutical manufacturing with batch process control and HART mass flow controllers; Water/wastewater treatment plants with HART-enabled flow meters and level sensors; Retrofit projects for legacy Foxboro I/A Series DCS systems upgrading to HART intelligent field device integration.

Technical Specifications
