TRICONEX 3805H 8-Channel 4-20 mA Analog Output Module for Tricon SIL 3 SIS
Product Description
The TRICONEX 3805H is a high-integrity Triple Modular Redundant (TMR) 8-channel analog output module, engineered by TRICONEX (Schneider Electric) for SIL 3 safety instrumented systems (SIS) in critical industrial environments. Supplied as a TMR set of 3 hot-swappable modules, it delivers precise 4–20 mA DC-coupled current outputs (with +6% overrange capability) to drive field actuators, control valves, and process instruments—enabling deterministic control in ESD, fire & gas (F&G), and process safety applications. Featuring 12-bit resolution, ±0.25% FSR accuracy (0–60°C), built-in loop diagnostics, and seamless integration with Tricon main/expansion chassis, it is ideal for oil & gas, chemical, petrochemical, and power generation industries.
Key Functions
The 3805H analog output module enables fault-tolerant, TMR-voted analog control for safety-critical and non-safety process loops. Key functions include: providing 8 DC-coupled 4–20 mA current outputs (commoned return, no per-point isolation); supporting +6% overrange (up to 21.2 mA) for valve stroke testing; implementing 2-out-of-3 majority voting for output integrity; hot-swappable design for online maintenance without system shutdown; LED status indicators (PASS/FAIL/ACTIVE/OUTPUT HEALTH) for real-time module and loop monitoring; and compatibility with external loop power (nominal 24 VDC, max 42.5 VDC) to drive high-impedance loads.
Application Scenarios
The TRICONEX 3805H analog output module is deployed in safety-critical industrial applications requiring precise, fault-tolerant analog control with SIL 3 compliance. In offshore platforms and refineries, it drives emergency shutdown (ESD) valves, pressure control valves, and turbine governors—ensuring rapid, reliable response to process upsets. In chemical plants, it modulates reactor feed valves, temperature control loops, and toxic gas mitigation systems, maintaining SIL 3 safety integrity. In power generation facilities, it controls boiler feedwater valves, turbine speed governors, and emission control systems, enabling real-time condition monitoring and protection. It is also used in mining, pharmaceutical manufacturing, and water/wastewater treatment—all scenarios where high-accuracy analog output and TMR fault tolerance are critical to preventing safety incidents.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output (AO) Module, TMR Set of 3 |
| Manufacturer | TRICONEX (Schneider Electric) |
| Model/Part Number | 3805H |
| Architecture | Triple Modular Redundant (TMR); 2-out-of-3 Majority Voting |
| Output Channels | 8 Channels; DC-Coupled, Commoned Return (No Per-Point Isolation) |
| Output Range | 4–20 mA (±0.25% FSR Accuracy); +6% Overrange (up to 21.2 mA) |
| Resolution | 12 Bits |
| Loop Power | External Loop Power; Nominal 24 VDC, Max 42.5 VDC |
| Operating Temperature | 0°C to +60°C (32°F to +140°F); Accuracy Valid in This Range |
| Safety Compliance | IEC 61508 SIL 3 Certified; FM, CSA, ATEX, IECEx Approved |
| Key Features | Hot-Swappable, TMR Fault Tolerance, LED Diagnostics, Loop Integrity Monitoring, Overrange Capability, Tricon Chassis Compatibility |
