Honeywell 8C-PCNT02 C300 Control & Pulse Counting Module

Product Description

The Honeywell 8C-PCNT02 is a high-performance integrated control and pulse counting module designed for Honeywell’s C300 controller series, offering seamless compatibility with Experion Process Knowledge System (PKS) and Experion LX Distributed Control Systems (DCS). Engineered for rugged industrial environments, this module features a protective conformal coating that resists moisture, dust, and chemical corrosion, ensuring stable operation even under extreme temperature and humidity conditions. Its compact, rack-mountable design optimizes cabinet space utilization, while plug-and-play functionality simplifies integration with existing control architectures, reducing commissioning time and maintenance costs. As a core component of distributed control systems, it combines dual functionality of process control and pulse signal processing to meet the diverse needs of modern industrial automation.

Key Functions

The 8C-PCNT02 operates as a dual-purpose module, executing high-speed deterministic process control strategies including regulatory control, sequence control, and discrete logic control via its 32-bit RISC processor, while simultaneously performing high-precision pulse counting for signals from encoders, flow meters, and proximity sensors, with a frequency range of 0.01 Hz to 100 kHz for accurate measurement of speed, flow, and position parameters. It supports real-time data acquisition and transmission to upper-level systems via Modbus, RS-232, and RS-485 protocols, features built-in redundancy to eliminate single-point failures and ensure uninterrupted operation, and provides comprehensive self-diagnostic functions to monitor module health and trigger alarms for faults such as signal loss and overvoltage. Additionally, it enables remote configuration and parameter adjustment through Honeywell’s Control Builder software, and integrates safety interlock logic to enhance operational reliability in critical applications.

Application Scenarios

This versatile module is widely deployed across process and discrete manufacturing industries, including oil and gas refineries for monitoring pipeline flow rates and pump speeds, chemical plants for controlling reactor sequences and counting batch production cycles, and power generation facilities for regulating turbine auxiliary systems and measuring generator rotational speed. It is also ideal for automotive production lines for tracking conveyor belt speeds and part counting, food and beverage processing plants for controlling packaging machine operations and monitoring filling volumes, and water and wastewater treatment facilities for measuring flow rates and controlling valve actuation sequences. Furthermore, it suits metallurgical processes for monitoring furnace temperature control cycles and material handling equipment speed, as well as building automation systems for managing HVAC equipment and energy consumption metering.

Technical Specifications
