Honeywell TK-IOLI01 51403427-175-2 I/O Link Interface Module--KIMI
  • Warehouse: Spot
  • Warranty: 365 days
  • Quality: Original module
  • Condition: New
  • Shipping method: Courier delivery

  • Contact person: LI MING
  • Contact number: +86 18059884790
  • WeChat:18059884790
  • E-mail: plc66@qq.com

Product Description


Honeywell TK-IOLI01 51403427-175-2 I/O Link Interface Module
Data Communication Bridge Between C200 Controller & I/O Modules for Experion PKS System
1. Product Overview

The Honeywell TK-IOLI01 51403427-175-2 is a dedicated I/O Link Interface module designed for the Experion PKS C200 controller system, serving as a critical communication bridge between the C200 control processor and distributed I/O modules. It supports high-speed data transmission over redundant I/O links, enabling real-time exchange of process data, control commands, and diagnostic information. The module features built-in fault detection and status indication functions, which can quickly identify link abnormalities and trigger alarms to ensure the stability of the control system. With compliance to Class I, Division 2 hazardous location standards and a compact design, it is widely used in petrochemical, power generation, and chemical industries, providing reliable I/O communication support for critical process control.


TK-IOLI01 51403427-175.jpg


2. Key Technical Specifications
• Product Type: I/O Link Interface Module (C200 Controller Series, Experion PKS)
• Brand: Honeywell (Part No.: TK-IOLI01, 51403427-175-2)
• Compatible System: Honeywell Experion PKS C200 Controller, Distributed I/O Modules
• Communication Interface: 2×Redundant I/O Link Ports, Supports High-Speed Data Transmission
• Data Transmission Rate: Up to 10 Mbps
• Power Supply: 24 VDC (150 mA), Redundant Power Input Supported
• Operating Temperature: 0°C to +60°C
• Storage Temperature: -40°C to +85°C
• Dimensions: 127 mm × 101.6 mm × 12.7 mm
• Weight: 0.4 kg
• Slot Occupation: 1 Dedicated Slot in C200 Controller Chassis
• Hazardous Location Certification: Class I, Division 2, Groups A-D, Temp Code T4

• Certifications: CE, UL, RoHS Compliant


TK-IOLI01 51403427-175 -2.jpg


3. Core Features
• Redundant I/O Link: Dual I/O link ports ensure uninterrupted data communication between controller and I/O modules.
• High-Speed Transmission: Up to 10 Mbps data rate for real-time process data exchange.
• Fault Detection & Alarm: Built-in diagnostic functions identify link faults and trigger timely alarms.
• Redundant Power Support: Dual 24 VDC power inputs enhance system availability and reliability.
• Compact Design: Occupies only 1 slot in C200 chassis, saving precious installation space.
• Hazardous Environment Adaptation: Certified for Class I, Division 2 hazardous industrial locations.

• Easy Integration: Plug-and-play installation, seamless integration with C200 controller and I/O modules.


TK-IOLI01 51403427-175 -1.jpg


4. Typical Applications
• Petrochemical Industry: Connects C200 controller with field I/O for refinery process control.
• Power Generation: Links turbine/generator control I/O modules to C200 controller for data acquisition.
• Chemical Plants: Establishes communication between batch process I/O and C200 control system.
• Oil & Gas: Connects wellhead monitoring I/O devices PH, temperature, and pressure to C200 controller.
• Water Treatment: Bridges C200 controller with water quality monitoring and treatment I/O modules.
5. Installation & Configuration
• Mounting: Install in 1 dedicated slot of C200 controller chassis; ensure secure slot connection.
• Wiring: Connect redundant I/O link ports to I/O modules; wire redundant 24 VDC power supplies.
• Configuration: Use Honeywell Control Builder software to set I/O link parameters and enable redundancy.
• Testing: Perform link redundancy test area to check auto-failover function after installation.
• Maintenance: Support online status monitoring and hot-swapping under redundant configuration.
Technical Document | Honeywell TK-IOLI01 51403427-175-2 | I/O Link Interface Module | Experion PKS C200 System
