The 269PLUS-D/O-111-100P-HI is an Allen-Bradley (Rockwell Automation) MPR-Plus Motor Protection Relay with a specific configuration of digital outputs, communication, current rating, and other features. This advanced electronic relay provides comprehensive protection, control, and monitoring for electric motors in demanding industrial applications.

English Description

The Allen-Bradley 269PLUS-D/O-111-100P-HI is a highly configurable MPR-Plus Motor Protection Relay. It goes beyond basic overload protection, offering a wide array of protective functions, extensive diagnostic capabilities, and robust communication options for integrating motors into modern control systems.

Let's break down the specific configuration from the part number:

• 269PLUS: This indicates the MPR-Plus Motor Protection Relay product family, known for advanced motor protection and monitoring features.

• D/O: This segment specifies the Digital Output configuration. While the exact number of outputs isn't stated by just "D/O," it indicates a particular set of discrete output relays that can be programmed for trip, alarm, control, or status indication.

• 111: This code typically represents the Communication Protocol and/or other specific features. For the 269PLUS, "111" often signifies Modbus RTU communication as the primary serial communication interface. It might also encompass specific internal logic or I/O options.

• 100P: This denotes the Primary Current Rating of the relay. "100P" means the relay is designed to monitor a primary current of 100 Amperes (A), usually through internal current transformers (CTs) or by being directly rated for this current.

• HI: This suffix often refers to a High-Intensity, High-Accuracy, or specific Hardware/Firmware Revision. In the context of motor protection, it could imply enhanced accuracy for metering, extended diagnostic capabilities, or a specific hardware variant optimized for certain conditions or functionalities.

General features of the 269PLUS family (which this configured unit possesses):

• Comprehensive Protection: Includes thermal overload (Class 5-30 selectable), phase loss/imbalance, stall, undercurrent/overcurrent, jam, ground fault, under/over voltage, and power factor monitoring.

• Metering: Provides real-time motor operating parameters like current (A), voltage (V), power (kW), energy (kWh), power factor, and frequency.

• Diagnostics: Extensive diagnostic information, including trip history, event logs, and fault codes, aiding in troubleshooting and predictive maintenance.

• Control Power: While not explicitly in this string, 269PLUS relays typically support a range of control power voltages (e.g., 100-240V AC/DC or 24-48V AC/DC).

• User Interface: Features a local liquid crystal display (LCD) and keypad for programming and viewing status.

• Mounting: Flexible mounting options, including direct mounting to contactors or standalone DIN rail/panel mounting.

• Applications: Ideal for pumps, fans, compressors, conveyors, and other motor-driven equipment where critical protection, detailed monitoring, and integration into a supervisory control system are required.

This specific 269PLUS configuration is suited for applications involving 100A primary currents, utilizing Modbus RTU communication, and benefiting from advanced features for robust motor management.

中文描述

269PLUS-D/O-111-100P-HI 是一款具有特定数字量输出、通信、电流额定值及其他功能的 艾伦-布拉德利 (罗克韦尔自动化) MPR-Plus 电机保护继电器。这种先进的电子继电器为工业应用中严苛的电机提供全面的保护、控制和监控。

主要特点和功能

艾伦-布拉德利 269PLUS-D/O-111-100P-HI 是一款高度可配置的 MPR-Plus 电机保护继电器。它超越了基本的过载保护功能，提供广泛的保护功能、丰富的诊断能力和强大的通信选项，可将电机集成到现代控制系统中。

下面分解此部件号中的具体配置：

• 269PLUS：这表示 MPR-Plus 电机保护继电器 产品系列，以其先进的电机保护和监控功能而闻名。

• D/O：此段指定数字量输出配置。“D/O”虽然没有直接说明输出数量，但它表示一组特定的离散量输出继电器，可编程用于跳闸、报警、控制或状态指示。

• 111：此代码通常代表通信协议和/或其他特定功能。对于 269PLUS，“111”通常表示以 Modbus RTU 通信 作为主要的串行通信接口。它还可能包含特定的内部逻辑或 I/O 选项。

• 100P：这表示继电器的一次电流额定值。“100P”意味着该继电器设计用于监控 100 安培 (A) 的一次电流，通常通过内部电流互感器 (CT) 或直接额定为该电流。

• HI：此后缀通常指高强度、高精度或特定的硬件/固件版本。在电机保护的语境中，它可能意味着更高的计量精度、扩展的诊断功能，或针对某些条件或功能优化的特定硬件变体。

269PLUS 系列的通用功能（此配置单元也具备）：

• 全面保护： 包括热过载（可选类别 5-30）、缺相/相不平衡、堵转、欠流/过流、卡滞、接地故障、欠压/过压以及功率因数监控。

• 计量： 提供实时电机运行参数，如电流 (A)、电压 (V)、功率 (kW)、能量 (kWh)、功率因数和频率。

• 诊断： 丰富的诊断信息，包括跳闸历史、事件日志和故障代码，有助于故障排除和预测性维护。

• 控制电源： 尽管在此字符串中未明确说明，但 269PLUS 继电器通常支持多种控制电源电压（例如，100-240V 交流/直流 或 24-48V 交流/直流）。

• 用户界面： 配备本地液晶显示屏 (LCD) 和键盘，用于编程和查看状态。

• 安装： 灵活的安装选项，包括直接安装到接触器或独立 DIN 导轨/面板安装。

• 应用： 适用于泵、风机、压缩机、输送机以及其他需要关键保护、详细监控和集成到监控控制系统的电机驱动设备。

此特定的 269PLUS 配置适用于涉及 100A 一次电流的应用，利用 Modbus RTU 通信，并受益于高级功能以实现强大的电机管理。
