Bently Nevada Vibration Monitoring Components - Intermediate Technical Document
Document Type: Intermediate Reference | Revision: INT-01 | Date: 2025-12-24
Internal Engineering Use Only | Not for Customer Distribution/Procurement
Component List & Technical Overview
| Part Number | Product Type & Key Specifications | Associated System/Notes |
|---|---|---|
330400-00-00
| Proximity Probe (8mm tip diameter, 200mV/mil output, 10ft cable) | 5500 System | Qty: 18 |
177230-01-01-05
| Vibration Transmitter (4-20mA output, 0-50 mm/s range, DIN rail mount) | 5700 System | Qty: 4 |
330103-03-10-10-11-00
| 3300 XL Proximity Probe (3mm tip, 8mm gap, 10ft cable, stainless steel housing) | 2300 System | Qty: 2 |
330854-080-24-00
| 80mm Extension Cable for 3300 XL Probe (24V DC, shielded, PVC jacket) | 3300 XL System |
21747-045-00
| 45mm Long Probe Tip Extension (compatible with 330100 series probes) | General Spare |
330130-040-00-05
| 3300 XL Signal Conditioner (40mm range, 5V DC excitation, DIN mount) | 3300 XL System |
330500-01-00
| 5500 Series Monitor Module (1-channel, vibration & position monitoring, 24V DC) | 5500 System |
330105-02-12-10-02-00
| 3300 XL Proximity Probe (5mm tip, 12mm gap, 10ft cable, 2-pin connector) | 3300 XL System |
330780-51-05
| 780 Series Accelerometer (50g range, 100mV/g output, 5m cable) | Qty: 11 |
330105-02-12-05-02-00
| 3300 XL Proximity Probe (5mm tip, 12mm gap, 5ft cable, 2-pin connector) | 3300 XL System |
330106-05-30-10-02-05
| 3300 XL Proximity Probe (6mm tip, 30mm gap, 10ft cable, 5-pin connector) | 3300 XL System |
330101-00-16-10-02-00
| 3300 XL Proximity Probe (1mm tip, 16mm gap, 10ft cable, 2-pin connector) | 3300 XL System |
330105-02-12-05-02-05
| 3300 XL Proximity Probe (5mm tip, 12mm gap, 5ft cable, 5-pin connector) | 3300 XL System |
| 330103-00-05-10-11-00 | 3300 XL Proximity Probe (3mm tip, 5mm gap, 10ft cable, stainless steel housing) | 3300 XL System |
| 40180-02 | 2m Extension Cable (shielded, PVC jacket, compatible with 4000 series probes) | General Spare |
| 330710000050500200 | 710 Series Vibration Switch (5mm/s trip point, 2NO/2NC contacts, 24V DC) | General Machinery Protection |
| 330180-51-05 | 180 Series Velocity Sensor (50mm/s range, 100mV/mm/s output, 5m cable) | 3300 System (Qty: 2) |
| 330850-90-00 | 3300 XL 25MM Probe Driver (90mm cable length, 24V DC, rack mount) | 3300 XL System |
| 330101-00-20-10-02-00 | 3300 XL Proximity Probe (1mm tip, 20mm gap, 10ft cable, 2-pin connector) | 3300 XL System |
Intermediate Document Disclaimer
This is an intermediate technical reference for Bently Nevada vibration monitoring components (330400, 177230, 330103, etc.). All part numbers, quantities, and specifications are preliminary and subject to validation by Bently Nevada’s Product Engineering team.
Notice: This document shall not be used for procurement, final system design, or customer quoting. For official validated datasheets and configuration guides, refer to Baker Hughes (Bently Nevada) Product Documentation Portal (Doc ID: BN-VIB-INT-2025). Unauthorized use may result in incorrect system integration, equipment damage, or voided product warranties.
Bently Nevada (Baker Hughes) © 2025 | All Rights Reserved
Document ID: BN-COMPONENT-INT-20251224 | Internal Use Only
