ABB 1TGE120021 Series - Intermediate Technical Document
Document Type: Intermediate Reference | Revision: INT-01 | Date: 2025-12-24
Internal Engineering Use Only | Not for Customer Distribution or Procurement
Component Specifications
| Part Number | Product Type & Key Specifications | Configuration Notes |
|---|---|---|
1TGE120021R0810
| Industrial Control Module (ABB ACS880/ACS580 Drive Series) • Power Supply: 24V DC (18-30V DC range) • Operating Temperature: -20°C to +60°C • Protection Class: IP20 (panel mount) • Communication: Modbus RTU (RS-485), Profibus DP | • 8 digital input channels • 10 digital output channels (relay type) • No analog I/O option enabled |
1TGE120021R0110
| Industrial Control Module (ABB ACS880/ACS580 Drive Series) • Power Supply: 24V DC (18-30V DC range) • Operating Temperature: -20°C to +60°C • Protection Class: IP20 (panel mount) • Communication: Modbus RTU (RS-485), Profibus DP | • 1 digital input channel • 10 digital output channels (transistor type) • No analog I/O option enabled |
Application & Compatibility
- Primary Applications: Variable Frequency Drive (VFD) control systems for industrial motors (pumps, fans, conveyors, compressors)
- Compatibility: ABB ACS880 (0.75kW to 5.6MW) and ACS580 (0.75kW to 250kW) AC drives; ABB PLC systems (AC500, AC31)
- Mounting: DIN rail mounting (EN 50022) or direct panel mounting via screws; Plug-in terminal connections for easy wiring
- Diagnostics: Built-in LED indicators (Power, Fault, Communication, I/O Status); Fault logging via drive software
Intermediate Document Disclaimer
This is an intermediate technical reference for ABB 1TGE120021R0810 and 1TGE120021R0110 control modules. All specifications, including I/O configurations and compatibility data, are preliminary and subject to validation by ABB Drive Products division.
Notice: This document shall not be used for procurement, final system design, or customer quoting. For official validated datasheets and installation guides, refer to ABB’s Product Documentation Portal (Doc ID: 1TGE120021-DS-01). Unauthorized use may result in incorrect system integration and voided product warranty.
ABB Drive Products © 2025 | All Rights Reserved
Document ID: ABB-1TGE120021-INT-20251224 | Internal Use Only
```
