- Brand：TRICONEX
- Part number：TRICON3601E
- Product Origin：America
- Weight：0.7KG
- HS CODE：8479909090
- RMB Market price：20000-30000
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
TRICONEX 3601E Digital Input Module Overview
The TRICONEX 3601E is a high-reliability digital input module designed by Triconex (a Schneider Electric brand), specifically engineered for integration with Triconex Safety Instrumented Systems (SIS). As a critical I/O component in safety-critical industrial control systems, it adopts a robust design to deliver accurate, real-time digital signal acquisition while complying with SIL 3 safety integrity level standards and IEC 61508/IEC 61511 international norms.
Optimized for harsh industrial environments, the module provides reliable connectivity for discrete sensors, switches, and other digital input devices. It works seamlessly with Triconex CPU modules (such as 3008, 3009, and 3009X) to form a complete safety control solution, ensuring critical process data is captured and transmitted with minimal latency—essential for emergency shutdown, fire & gas protection, and other high-risk applications.
Core Features & Technical Advantages
- High-Density Input Channels: Configured with 16 independent digital input channels, supporting both sinking (NPN) and sourcing (PNP) input types for flexible compatibility with various field devices.
- Enhanced Signal Integrity: Incorporates optical isolation (500VDC) between channels and backplane, plus surge protection (IEC 61000-4-5) to resist electromagnetic interference (EMI) and voltage transients common in industrial settings.
- Wide Voltage Compatibility: Accepts input voltage ranges of 24VDC (standard) and 120VAC/240VAC (optional), adapting to global industrial power specifications without additional adapters.
- Rapid Response Time: Typical input response time of ≤1ms (configurable up to 10ms) for critical signals, ensuring fast detection of process anomalies and timely system intervention.
- Built-in Self-Diagnostics: Continuous monitoring of channel status, power supply, and communication links with 99.9% diagnostic coverage. Fault information is transmitted to the CPU module for real-time alerting and logging.
- Hot-Swappable Design: Supports online insertion and removal without system shutdown, minimizing maintenance downtime and enhancing operational continuity.
- Seamless System Integration: Fully compatible with Triconex TMR architecture and TriStation 1131 programming software, enabling easy configuration, calibration, and status monitoring via the SIS controller.
Robust Mechanical Construction: Industrial-grade metal housing with IP65 protection rating, designed to withstand vibration (IEC 60068-2-6) and extreme temperatures in harsh field conditions.
Key Technical Specifications
| Specification Category | Details | Remarks |
|---|---|---|
| Input Configuration | 16 digital input channels (isolated) | Channel-to-channel isolation: 500VDC |
| Input Voltage | 24VDC (18-32VDC); Optional 120VAC/240VAC | Wide range for global industrial use |
| Response Time | ≤1ms (standard); 1-10ms (configurable) | Adjustable for different application needs |
| Environmental Ratings | Operating Temp: -40°C to 85°C; Humidity: 5-95% (non-condensing) | Suitable for extreme industrial conditions |
| Power Consumption | ≤5W (24VDC); ≤8W (AC version) | Low power for energy efficiency |
| Physical Dimensions | 220mm × 140mm × 80mm (W×H×D) | Fits standard Triconex racks |
| Certifications | SIL3 (IEC 61508), UL, CE, ATEX, IECEx | Compliant with global safety standards |
Application Scenarios & YMGK Purchase Support
Target Industries & Use Cases
The TRICONEX 3601E is widely used in industries requiring strict safety control, including:
Oil & Gas
Wellhead monitoring, pipeline pressure switches, emergency shutdown triggers
Chemical & Pharmaceutical
Tank level switches, valve position sensors, hazardous gas detector inputs
Power Generation
Boiler safety switches, turbine status sensors, generator protection inputs
Metallurgy & Mining
Smelter temperature switches, conveyor emergency stops, dust collector sensors
YMGK Procurement Services
- Global 121 shared inventories, direct procurement from overseas warehouses for fast delivery
- 100% brand new and original products with one-year warranty and professional testing certification
- Volume discounts available for multi-module orders; price matching with other suppliers
- Technical support for module configuration, integration, and troubleshooting
