TRICONEX MODULES & 8111 EXPANSION CHASSIS (MP3009 / 4351B / 3721 / 3604E / 8311)
TMR Safety-Critical Components with 8111 Chassis for SIL 3 System Expansion
1. TRICONEX MP3009 TMR Main Processor Module
The TRICONEX MP3009 is a high - performance TMR main processor for Tricon V10/V11 safety systems, featuring a 32 - bit MPC860 processor, expanded memory, and advanced diagnostics. It executes control logic, manages TriBus communication, and achieves fault tolerance via hardware majority voting, supporting SIL 3 applications with hot - swappable maintenance and comprehensive SOE event logging.
• Core Specs: 32 - bit 50 MHz MPC860; TriBus 25 Mbps; 16 MB DRAM, 4 MB Flash; 24 V DC (20 - 32 V DC); ≤ 5 W; SIL 3 (IEC 61508)
• Key Features: TMR 3 - 2 - 1 voting; SOE 1000 - event buffer; hot - swappable; - 40°C to +70°C operation
2. TRICONEX 4351B Tricon Communication Module (TCM)
The 4351B is a dual - Ethernet (10/100 Mbps) and 4 - serial (RS - 232/485) TMR communication module, enabling secure data exchange between Tricon controllers, TriStation 1131, and external systems. It supports Modbus RTU/ASCII, TCP/IP, and TSAA protocols, with 500 VDC port isolation for reliable communication in industrial environments.
• Core Specs: 2× 10/100 Ethernet, 4× RS - 232/485; 500 VDC isolation; 24 V DC; ≤ 3 W; SIL 3 compliant
• Key Features: Dual Ethernet redundancy; 4 isolated serial ports; hot - swappable; GPS time sync support
3. TRICONEX 3721 32 - Channel Differential Analog Input Module
The 3721 is a 32 - channel TMR analog input module with differential inputs for 0-5 VDC or - 5 to +5 VDC signals, delivering 12/14 - bit programmable resolution and ±0.15% accuracy for precise process variable measurement in critical applications.
• Core Specs: 32 differential channels; 10 ms update rate; 150 VDC/115 VAC overrange protection; 24 V DC; ≤ 3 W
• Key Features: TMR signal voting; channel isolation; programmable resolution; common - mode rejection (- 85 dB)
4. TRICONEX 3604E 16 - Channel TMR Digital Input Module
The 3604E is a 16 - channel 24 VDC opto - isolated TMR digital input module with non - commoned channels, designed for monitoring safety - critical field devices like emergency stop buttons and trip switches. It features channel - level isolation and TMR voting for fault - safe signal acquisition.
• Core Specs: 16 isolated channels; 24 V DC (18 - 32 V DC); 500 VDC isolation; ≤ 2.5 W; - 40°C to +70°C
• Key Features: TMR 3 - 2 - 1 voting; channel fault isolation; supervised inputs; hot - swappable
5. TRICONEX 8311 24 V DC Redundant Power Module
The 8311 is a redundant 24 V DC power module for Tricon main and 8111 expansion chassis, providing 20 - 32 V DC regulated output with overload and short - circuit protection. It supports hot - swapping and redundant configuration to ensure continuous power supply for safety - critical systems.
• Core Specs: 24 V DC (20 - 32 V DC) output; 175 W max power; 2 - wire redundant input; ≤ 1.2 kg
• Key Features: Redundant design; overload/short - circuit protection; hot - swappable; LED status indicators
6. TRICONEX 8111 High - Density Expansion Chassis
The TRICONEX 8111 is a 19 - inch rack - mountable expansion chassis for Tricon SIS, supporting up to 10 I/O/communication modules to extend system capacity. It features a rugged design, redundant power (8311 modules), and hot - swappable module slots, enabling seamless integration with Tricon main chassis for distributed I/O expansion in harsh industrial environments.
• Core Specs: 10 module slots; 19 - inch rack - mount; 483mm×178mm×419mm; 22.7 kg; 100-240 VAC/24 V DC (via 8311)
• Key Features: Redundant power bays; hot - swappable slots; TriBus interface; - 40°C to +70°C operation
System Integration & Typical Applications
Chassis - Module Compatibility: 8111 chassis supports MP3009, 4351B, 3721, 3604E, and 8311 modules; connects to Tricon main chassis via TriBus for distributed I/O expansion.
Key Applications: Oil & gas ESD, petrochemical reactor control, power generation turbine protection, chemical batch safety, marine/offshore SIS.
Safety Certifications: All components hold IEC 61508 SIL 3, ATEX, IECEx, CE, UL certifications for global compliance.
