5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152 IGCT MODULE--KIMI

Part number：5SHX1445H0001 3BHL000391P0001
Product Origin：Sweden
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

5SHX1445H0001 | 3BHL000391P0001 | ABB IGCT Driver Board

IGBT/IGCT Gate Driver Module for ACS1000 Medium-Voltage Drives

1. Product Overview

The ABB 5SHX1445H0001 (order code: 3BHL000391P0001) is a dedicated IGCT (Integrated Gate-Commutated Thyristor) driver board designed for ABB ACS1000 series medium-voltage variable frequency drives (VFDs). It integrates gate drive circuits, protection logic, and interface functions to control and protect high-power IGCT modules in medium-voltage inverter applications, ensuring reliable switching and fault protection. The board features 24V DC power input, isolated signal transmission, overcurrent/overvoltage/overtemperature protection, and compatibility with ACS1000 drive control systems, supporting 3.3kV–6.6kV voltage levels and high-current operation (up to 1445A). Its rugged design and industrial-grade components enable operation in harsh environments (-25°C to +70°C), making it suitable for power generation, oil & gas, metallurgy, and heavy industry motor control systems.

ABB 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152 (5).png

产品ID:3BHL000391P0101

ABB型号名称:5SHX1445H0001

目录说明:5SHX1445H0001; IGCT MODULE

详细描述:5SHX1445H0001

更换产品ID（OLD）:

3BHL000391P0001

HL000391P0101

产品净高:45 mm

产品净重:2.11 kg

产品净宽:200 mm

产品净深:240 mm

Key Specifications

• Model: 5SHX1445H0001 | Order Code: 3BHL000391P0001 | Brand: ABB

• Type: IGCT Driver Board for ACS1000 Medium-Voltage Drives

• Power Input: 24V DC (typical), Max 2A Current Consumption

• Protection Features: Overcurrent (OC), Overvoltage (OV), Overtemperature (OT), Short-Circuit Protection

• Isolation: Signal Isolation (2.5kV), Power Isolation for Gate Drive

• Compatibility: ABB ACS1000 Series Medium-Voltage VFDs, 3.3kV–6.6kV Systems

• Operational Temperature: -25°C to +70°C; Storage Temperature: -40°C to +85°C

• Physical: PCB Form Factor, Industrial-Grade SMT Components, Conformal Coating Option

• Certifications: CE, RoHS, IEC 61800-5-1 Compliance

ABB 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152 (4).png

2. Core Features

• Dedicated IGCT Drive: Optimized gate control for high-power IGCT modules, ensuring fast, reliable switching

• Comprehensive Protection: Overcurrent/overvoltage/overtemperature monitoring with fast fault response (<10μs) to protect IGCTs and drives

• Isolated Signal Interface: 2.5kV isolated signal transmission between control and power stages to prevent noise interference

• ACS1000 Compatibility: Seamless integration with ABB ACS1000 drive control systems, plug-and-play installation

• Industrial Ruggedness: Conformal coating option for harsh environments, vibration/shock resistance per IEC 60068

• Diagnostic Functions: LED status indicators for power, drive status, and fault conditions for quick troubleshooting

ABB 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152 (3).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

3. Typical Applications

• Medium-Voltage Drives: ABB ACS1000 series VFDs for 3.3kV–6.6kV industrial motors

• Power Generation: Boiler feed pumps, induced draft fans, and turbine control systems

• Metallurgy: Rolling mill drives, blower systems, and conveyor belt motor control

• Oil & Gas: Compressor drives, pump systems, and pipeline motor control

• Water & Wastewater: Large water pump VFD systems for water treatment plants

• Heavy Industry: Cement mill drives, paper machine drives, and other high-power motor applications

4. Installation & Maintenance

Installation: Mount on ACS1000 drive control cabinet backplane; connect 24V DC power, signal cables (gate drive, feedback), and control bus; verify LED indicators (Power ON, Drive Ready, No Fault).

Maintenance: Weekly: Check LED status and power connections; Monthly: Inspect signal cables and isolation integrity; Annual: Test protection functions, check conformal coating, and update firmware (if applicable).

Safety Notes: De-energize drive before installation/maintenance; use ESD protection; follow ABB ACS1000 safety guidelines; ensure proper grounding and isolation.
