ABB CP675-WEB - Intermediate Technical Document
Document Type: Intermediate Reference | Revision: INT-01 | Date: 2025-12-24
Internal Engineering Use Only | Not for Customer Distribution or Procurement
Core Product Specifications
| Product Identification | Model: CP675-WEB Order Code: 1SAP575200R000 |
| Product Type | Industrial HMI Panel (Web-enabled Operator Interface Terminal) |
| Display Specifications | • Size: 7-inch TFT LCD (16:9 aspect ratio) • Resolution: 800 x 480 pixels (WVGA) • Brightness: 350 cd/m² • Touchscreen: Resistive (4-wire), IP65 front protection |
| Processing & Memory | • CPU: ARM Cortex-A9 (800MHz) • RAM: 512MB DDR3 • Flash Storage: 1GB (expandable via microSD) |
| Communication Interfaces | • Ethernet: 1 x 10/100 Mbps RJ45 (Web server, Modbus TCP, PROFINET) • USB: 1 x USB 2.0 (host), 1 x USB 2.0 (device) • Serial: 1 x RS-232/RS-485 (Modbus RTU, ASCII) |
| Power Supply | • Input: 24V DC (18-30V DC range) • Power Consumption: ≤ 12W (typical) • Redundancy: Optional dual power input (via accessory) |
| Environmental Ratings | • Operating Temperature: 0°C to +50°C • Storage Temperature: -20°C to +60°C • Humidity: 5-95% (non-condensing) • Protection Class: IP65 (front), IP20 (rear) |
| Software & Compatibility | • Pre-installed: ABB Panel Builder 800 Runtime • Web Server: Built-in HTTP/HTTPS server for remote monitoring/control • Compatibility: ABB AC500 PLCs, ABB drives (ACS880/ACS580), third-party PLCs (Modbus-compatible) |
Application & Configuration Notes
- Primary Applications: Industrial automation systems (manufacturing lines, process control, HVAC, water/wastewater treatment, power distribution)
- Mounting Options: Panel mount (flush/front), desktop mount (with optional stand), wall mount (via bracket)
- Order Code 1SAP575200R000: Standard configuration (7-inch display, web server enabled, no extended warranty, no language localization)
- Diagnostics: Built-in self-test (display, touchscreen, communication); Event logging to flash storage or remote server via Ethernet
Certifications (Preliminary): CE (2014/30/EU), UL 61010-1, cULus, RoHS 2011/65/EU
Product News ACM 18 2014 CP665.pdf
Intermediate Document Disclaimer
This is an intermediate technical reference for ABB CP675-WEB (Order Code: 1SAP575200R000) HMI panel. All specifications, including hardware configurations and compatibility data, are preliminary and subject to validation by ABB Industrial Automation division.
Notice: This document shall not be used for procurement, final system design, or customer quoting. For official validated datasheets and configuration guides, refer to ABB’s Product Documentation Portal (Doc ID: CP675-WEB-1SAP575200R000-DS). Unauthorized use may result in incorrect system integration and voided product warranty.
ABB Industrial Automation © 2025 | All Rights Reserved
Document ID: ABB-CP675-WEB-INT-20251224 | Internal Use Only
```
