DS200AAHAH2A Communication Board Origina New In Stock
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: DS200AAHAH2A – GE Mark V AAHA Gen2 ARCNET Hub Communication Board
GE DS200AAHAH2A | Second Generation ARCNET HUB LAN Driver PCB for Speedtronic Mark V LM Turbine Control System
DS200AAHAH2A is the 2nd generation AAHA ARCNET communication bare PCB board developed by GE for the legacy Speedtronic Mark V LM turbine control platform, upgraded iteration of DS200AAHAH1A series base boards. It acts as the core ARCNET bus hub inside Mark V control racks, realizing bidirectional deterministic real-time data transmission between main CPU core, local mini-operator terminal (323A2374P3), remote Genius distributed I/O stations and auxiliary drive cabinets. Compared with Gen1 DS200AAHAH1A, the 2nd generation optimizes circuit anti-interference, bus signal processing chip and power filtering circuit, supporting larger network node expansion and longer bus cable transmission distance. Each Mark V rack configures two AAHA boards for dual redundant communication to guarantee uninterrupted transmission of turbine speed, load, valve regulation and safety trip signals.
Core Technical Specifications
- Part Number: DS200AAHAH2A | Abbreviation: AAHA Gen2 | Brand: General Electric | Platform: Speedtronic Mark V LM
- Product Type: Second-generation ARCNET HUB LAN driver bare printed circuit board
- Front Network Interfaces: Dual ARCNET BNC ports ARCBNC-A / ARCBNC-B, spare EBNC reserved backup port
- Internal Board Connectors: 10-pin APL bus interface (docking UCIA / PANA / UCPB internal daughterboards), 2PL auxiliary power signal terminal
- Industrial Bus Protocol: Token-passing ARCNET deterministic real-time fieldbus, dedicated for synchronous turbine control data polling
- Rack Power Supply: +5VDC logic power supplied by Mark V rack backplane, optimized low ripple power filter circuit
- Redundancy Architecture: Dual AAHA Gen2 boards collocation to realize fully redundant ARCNET communication channel backup
- PCB Protection: Standard factory conformal coating, dust-proof, moisture-proof and anti-corrosive gas treatment for power plant cabinet environments
- Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
- Mounting Form: Single-slot standard plug-in card for Mark V control rack backplane
- Certifications: CE, UL industrial EMC anti-interference, power generation safety standard compliance
- Version Difference: DS200AAHAH2A = Gen2 optimized PCB; DS200AAHAH1A = Gen1 original base PCB; suffix ED/ADC are fully assembled finished assembly variants
Main Functional Features
- Dual BNC ARCNET ports support daisy-chain network topology, expand access for more remote Genius I/O stations and local HMI mini-terminals
- Dual-board split communication architecture: one board dedicated to local operator terminal communication, one for remote distributed I/O core interconnection
- Optimized APL dedicated internal bus, higher bandwidth data exchange with all auxiliary daughterboards mounted inside the main control rack
- Upgraded multi-stage differential isolation and surge suppression circuit, stronger anti-EMI capability for high-voltage excitation and medium voltage drive cabinet environments
- Built-in full communication self-diagnosis logic, real-time alarm for bus disconnection, signal attenuation, board power loss and chip communication abnormal faults
- Supports hot-swap replacement under redundant rack configuration, no full unit shutdown required during equipment maintenance and overhaul
- Token-passing ARCNET bus cycle ensures microsecond-level real-time transmission of critical turbine control and protection interlock signals, no data collision risk
- Fully backward compatible with DS200CPU main CPU board, DS200ADPAG1 Genius adapter board and 323A2374P3 local mini operator terminal
Application Industries
- Combined Cycle & Thermal Power Plant: Mark V gas/steam turbine main control rack second-generation ARCNET network communication core board
- Oil & Gas Industry: Onshore gathering station and offshore platform turbine generator distributed I/O communication system
- Hydropower Station: Large generator EX2100 excitation system remote parameter monitoring communication equipment
- Industrial Cogeneration Station: Reciprocating engine generator set local HMI and remote field signal transmission rack
- Equipment Retrofit & Maintenance: Upgrade replacement spare PCB for aging Gen1 DS200AAHAH1A series ARCNET communication modules
Product Picture
