DS200AAHAH1AED Assembly Board Origina New In Stock
- Part number：DS200AAHAH1AED
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: DS200AAHAH1AED – GE Mark V AAHA ARCNET Hub Communication Assembly Board
GE DS200AAHAH1AED | Full Assembled ARCNET Communication Card for Speedtronic Mark V Turbine Control System
DS200AAHAH1AED is the complete assembled revision of the GE AAHA ARCNET communication board under the Speedtronic Mark V platform. The base bare PCB model is DS200AAHAH1A, while suffix ED represents full assembled hardware revision E and drawing revision D, fully fitted with all original components, connectors, isolation circuits and conformal coating. It serves as the redundant ARCNET bus hub inside Mark V control racks, realizing bidirectional real-time communication between main CPU, local mini-operator terminals (323A2374P3), Genius remote I/O stations and auxiliary drive cabinets. Two AAHA boards are deployed in one rack for dual communication redundancy to guarantee uninterrupted data transmission of turbine speed, load, valve regulation and protection interlock signals.
Core Technical Specifications
- Full Part Number: DS200AAHAH1AED | Base PCB: DS200AAHAH1A | Abbreviation: AAHA | Brand: General Electric | Platform: Speedtronic Mark V LM
- Product Type: Fully assembled ARCNET HUB LAN communication interface assembly card
- Front Network Ports: Dual ARCNET BNC connectors ARCBNC-A / ARCBNC-B for daisy-chain field bus wiring, spare EBNC reserved port
- Internal Interfaces: 10-pin APL bus connector for docking UCIA / PANA / UCPB daughterboards, 2PL auxiliary power signal terminals
- Communication Protocol: Deterministic industrial ARCNET real-time bus, dedicated for synchronous turbine control data polling
- Rack Power Supply: +5VDC logic power supplied by Mark V rack backplane, low power consumption design
- Redundancy Configuration: Dual AAHA boards deployed per rack for redundant communication channel backup
- PCB Treatment: Full factory conformal coating, dust-proof, moisture-proof and anti-corrosive gas for power plant cabinet environments
- Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
- Mounting Form: Single-slot standard plug-in card for Mark V control rack backplane
- Certifications: CE, UL industrial EMC anti-interference, power generation safety standard compliance
- Difference from DS200AAHAH1A: DS200AAHAH1A is bare printed circuit board; AED version is fully populated finished assembly ready for direct rack installation
Main Functional Features
- Dual BNC ARCNET ports support daisy-chain topology, expand access for multiple remote Genius I/O stations and local HMI terminals
- Dual-board split communication architecture: one board for local mini-terminal operation communication, one for remote distributed I/O interconnection
- APL dedicated internal bus realizes high-speed data exchange with all auxiliary daughterboards mounted inside the main control rack
- Integrated signal isolation and surge suppression circuits, suppress high-frequency EMI interference from high-voltage excitation and medium voltage drive cabinets
- Built-in communication self-diagnosis logic, real-time alarm for bus disconnection, signal attenuation and board power loss faults
- Supports hot-swap replacement under redundant rack configuration, no full unit shutdown required during equipment maintenance and overhaul
- Deterministic ARCNET bus cycle ensures microsecond-level real-time transmission of critical turbine control and protection signals
- Full compatibility with DS200CPU main CPU board, DS200ADPAG1 Genius adapter board and 323A2374P3 local mini operator terminal
Application Industries
- Combined Cycle & Thermal Power Plant: Mark V gas/steam turbine main control rack ARCNET network communication core assembly
- Oil & Gas Industry: Onshore gathering station and offshore platform turbine generator distributed I/O communication system
- Hydropower Station: Large generator EX2100 excitation system remote parameter monitoring communication equipment
- Industrial Cogeneration Station: Reciprocating engine generator set local HMI and remote field signal transmission rack
- Equipment Retrofit & Maintenance: Direct replacement spare assembly for aging Mark V turbine ARCNET communication modules
Product Picture
