Product: DS200AAHAH1A – GE Mark V AAHA ARCNET Hub Communication Board
GE DS200AAHAH1A | ARCNET LAN Driver Interface Card for Speedtronic Mark V Turbine Control System
DS200AAHAH1A (AAHA Board) is a dedicated ARCNET communication hub circuit board developed by GE for the classic Speedtronic Mark V LM turbine control platform. It acts as the core protocol conversion bridge between the rackmain control engine, internal I/O cores, local mini-terminal HMI and remote distributed ARCNET field devices. Each Mark V control rack is equipped with two AAHA boards for dual redundant communication: one connects the main CPU core to local operator panels, the other links the main engine to remote Genius I/O stations and auxiliary drive cabinets, realizing stable bidirectional real-time data transmission based on industrial ARCNET bus protocol.
Core Technical Specifications
- Part Number: DS200AAHAH1A | Abbreviation: AAHA | Brand: General Electric | Platform: Speedtronic Mark V LM Series
- Board Type: ARCNET HUB LAN Driver Communication Interface PCB
- Front Communication Ports: ARCBNC-A / ARCBNC-B dual ARCNET BNC bus ports, spare EBNC unused port
- Internal Connectors: 10-pin APL bus connector (docking UCIA/UCPB/PANA daughterboards), 2PL auxiliary power signal terminal
- Bus Protocol: Industrial ARCNET deterministic real-time fieldbus, dedicated for turbine control synchronous data polling
- Rack Power Supply: +5VDC logic power supplied by Mark V backplane, low power consumption design
- Redundancy Architecture: Dual AAHA board collocation to realize redundant ARCNET communication channel backup
- PCB Protection: Full conformal coating, dust-proof, moisture-proof and anti-corrosive gas treatment
- Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
- Mounting: Single-slot standard plug-in card for Mark V control rack backplane
- Certifications: CE, UL industrial EMC anti-interference, power generation safety standard compliance
Main Functional Features
- Dual ARCNET BNC ports support daisy-chain network wiring, expand multi-point remote I/O and HMI device access capacity
- Two-board split communication architecture: one for local HMI/mini-terminal communication, one for remote I/O core interconnection
- APL dedicated bus interface realizes high-speed data exchange with UCIA, PANA, UCPB internal daughterboards inside the control rack
- Built-in bus signal isolation and surge suppression circuit, effectively resist high-frequency EMI interference in power plant high-voltage cabinet environment
- Complete communication self-diagnosis function, monitor ARCNET bus disconnection, signal attenuation and board power failure faults in real time
- Supports hot-swap replacement under redundant rack configuration, no full unit shutdown required during maintenance overhaul
- Deterministic ARCNET bus cycle ensures microsecond-level real-time transmission of turbine speed, load, valve control and protection signals
- Fully compatible with DS200CPU main CPU board, DS200ADPAG1 Genius adapter board and 323A2374P3 mini operator terminal
Application Industries
- Combined Cycle & Thermal Power Plant: Mark V gas/steam turbine main control rack ARCNET network communication core card
- Oil & Gas Industry: Onshore gathering station and offshore platform turbine generator distributed I/O communication system
- Hydropower Station: Large generator EX2100 excitation system remote parameter monitoring communication equipment
- Industrial Cogeneration Station: Reciprocating engine generator set local HMI and remote field signal transmission rack
- Equipment Retrofit & Maintenance: Spare replacement for aging Mark V turbine control ARCNET communication interface boards
Product Picture
