DSBC170 | Advant OCS Master Bus Communication Module--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB DSBC170 | Advant OCS Master Bus Communication Module

High-Speed Bus Repeater for Reliable Data Exchange in Distributed Control Systems

1. Product Overview

The ABB DSBC170 is a high-performance master bus communication module and bus repeater engineered for ABB Advant OCS distributed control systems, serving as a critical interface to enable seamless and high-speed data transmission between controllers, I/O modules, and field devices in industrial automation networks. It features robust bus signal repeating capability with 2500V AC isolation between bus segments, supporting the Advant Master Bus protocol for deterministic data exchange, ensuring reliable communication even in noisy industrial environments with long cable runs or multiple network nodes. Equipped with LED status indicators for bus activity, error detection, and power supply, it facilitates quick troubleshooting and system monitoring, making it an essential component for maintaining operational continuity in process control, power generation, and manufacturing automation applications.

DSBC170 (3).jpg

Key Specifications

• Manufacturer: ABB

• Model: DSBC170 (Part Number: 57310256-DB)

• Product Line: ABB Advant OCS Master Bus Module

• Product Type: Master Bus Communication Module / Bus Repeater

• Communication Protocol: Advant Master Bus

• Bus Speed: Up to 1 Mbps

• Isolation Voltage: 2500V AC (Bus Segment Isolation)

• Operating Voltage: 24 VDC (Typical)

• Current Consumption: 100 mA (Max)

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Dimensions (W×H×D): 107.9 × 90.5 × 110.3 mm

• Weight: 0.43 kg

• LED Indicators: Power, Bus Activity, Error, Status

• Mounting: ABB Advant OCS Standard Chassis

• Certifications: CE, UL Compliant

2. Core Features

• Bus Signal Repeating: Enhances signal integrity and extends communication distance for distributed I/O networks.

• High Isolation Protection: 2500V AC isolation between bus segments prevents electrical interference and ensures system safety.

• Deterministic Communication: Supports Advant Master Bus protocol for real-time, predictable data exchange in control systems.

• Visual Status Monitoring: LED indicators for power, bus activity, and errors enable rapid fault diagnosis and system maintenance.

• Industrial-Grade Reliability: Robust design withstands harsh industrial environments with stable performance in extreme temperatures.

• Seamless Integration: Designed for ABB Advant OCS systems, ensuring compatibility with controllers and I/O modules.

DSBC170 (2)(1).jpg

3. Typical Applications

• ABB Advant OCS Distributed Control Systems: Acts as a bus repeater for extending master bus communication in large-scale process control networks.

• Process Automation: Enables reliable data exchange between controllers and field I/O in chemical, petrochemical, and pharmaceutical plants.

• Power Generation: Supports communication in thermal power plants, hydropower stations, and renewable energy systems for monitoring and control.

• Manufacturing Automation: Facilitates high-speed data transmission in automotive, electronics, and food & beverage production lines.

• Oil & Gas: Ensures stable communication in upstream, midstream, and downstream operations, including refineries and pipeline monitoring.

DSBC170 (1).jpg

4. Installation & Maintenance

Installation: Mount on ABB Advant OCS chassis; connect 24 VDC power (100 mA max); wire bus segments to input/output terminals; verify isolation and proper grounding; check LED indicators for normal operation.

Maintenance: Regularly inspect bus cable connections for tightness and corrosion; monitor LED status for error detection; clean module terminals to prevent dust accumulation; replace faulty modules to avoid communication downtime.

Fault Diagnosis: Use LED indicators to identify power issues, bus errors, or activity problems; check bus cable integrity and termination resistors; verify isolation voltage for segment protection; test communication speed and data integrity with diagnostic tools.
