Rexroth PPC-R22.1N-T-Q1-P2-NN-FW Multi-Axis Motion Controller

Product Description

The PPC-R22.1N-T-Q1-P2-NN-FW is a high-performance multi-axis motion and logic controller from Bosch Rexroth Indramat PPC series, also part of VisualMotion 10 platform. It is designed for RECO 02 rack installation, IP20 protection, powered by 24V DC. It supports up to 40 digital drives via SERCOS real-time bus, equipped with PROFIBUS-DP slave interface, Q1 encoder channel and P2 servo valve interface, widely used for coordinated motion and hydraulic closed-loop control.

Product Functions

• Multi-axis synchronized motion control, electronic cam, electronic line shafting and positioning
• High-speed encoder signal acquisition via Q1 channel for SIN/COS or incremental encoders
• P2 dedicated analog output for proportional valves and electro-hydraulic servo valves
• SERCOS fiber real-time communication with Rexroth digital servo drives
• PROFIBUS-DP slave communication to exchange data with upper PLC or HMI
• 3 optional expansion slots for adding I/O and communication modules
• Programmable under IEC 61131-3 by IndraWorks, with status LED and reset button

Application Scenarios

• Hydraulic test benches, fatigue test machines and material testing equipment
• Metal forming machinery, hydraulic presses and injection molding machines
• Packaging, printing, textile and high-speed production line automation
• Robotics, gantry systems and multi-axis synchronous equipment
• Retrofit and spare replacement for old Rexroth Indramat control systems
