Bosch Rexroth R911170900 Product Description
The R911170900 is a Rexroth Indramat I/O module, also labeled as RMK12.2-IBS, used for INTERBUS fieldbus remote digital I/O expansion. It is a compact rack-mount slave module for Indramat legacy automation systems, handling digital input and output signals between field sensors/actuators and the main controller via INTERBUS. It is widely used as spare part for older production lines equipped with Indramat DIAX, EcoDrive and PPC motion controllers. This product is end-of-life, no longer in original production, only available as surplus or refurbished spare inventory.
Product Features
- Part number R911170900 = RMK12.2-IBS, INTERBUS remote digital I/O slave module for Indramat automation platform
- Digital input and digital output channels for connecting proximity sensors, limit switches, solenoid valves and relay loads
- INTERBUS fieldbus interface, daisy-chain bus topology, communicates with Rexroth Indramat motion controllers and PLC
- 24 VDC logic supply, short-circuit protection for output channels, built-in channel status LED indicators
- Modular DIN rail mounting design, easy installation inside machine control cabinets
- Onboard channel diagnostics, can report short circuit, overload and communication failure to master controller
- Works together with Indramat PPC series motion controllers, DIAX04 / EcoDrive03 servo drive systems
- Original manufacturing discontinued; firmware preloaded, basic configuration required after replacement
Application Scenarios
- Legacy packaging machinery with Indramat PPC motion control system, field digital signal collection
- Printing and converting machines using INTERBUS fieldbus remote I/O signal distribution
- Automated assembly lines, material handling equipment sensor and valve control signal interface
- Retrofit and spare part replacement for old Indramat RMK series I/O modules
- Food & beverage automation equipment maintenance projects for INTERBUS based control cabinets
- Special-purpose machinery with Indramat multi-axis servo systems requiring distributed digital I/O expansion
Frequently Asked Questions
A1: R911170900 is the Rexroth material number, the module type designation is RMK12.2-IBS, INTERBUS remote I/O module.
A2: Only compatible with same RMK12.2-IBS variant. Different RMK models have different channel count or bus interfaces, cannot be swapped without checking I/O definition and bus protocol.
A3: Check bus cable continuity, bus termination resistor, 24VDC module power supply, bus wiring sequence, and master side INTERBUS configuration.
A4: Hot swap is not recommended. Disconnect 24VDC power before removing module; otherwise it may trigger bus interruption and machine emergency stop.
A5: Use anti-static wrist strap during handling. Avoid overvoltage on I/O terminals. Store in dry environment, keep original packaging for spare stock.
