BENTLY 24765-01-01 Casing Expansion Sensor Origina New In Stock
- Part number：BENTLY 24765-01-01
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: 24765-01-01 – Bently Nevada Casing Expansion Sensor (LVDT)
Bently Nevada 24765-01-01 / 24765 Series DC-LVDT Housing Assembly
24765-01-01 is a **DC-LVDT based casing expansion sensor** (机壳膨胀传感器) by Bently Nevada (now part of Baker Hughes), used for measuring thermal expansion of large steam turbine casings in power plants and heavy machinery.
Key Specifications
- Part Number: 24765-01-01
- Manufacturer: Bently Nevada (Baker Hughes)
- Type: DC-LVDT Casing Expansion Sensor
- Linear Range: ±12.7 mm (±0.5 in) / total 25.4 mm (1.0 in)
- Scale Factor: 0.346 V/mm (8.79 V/in)
- Input Power: +24 VDC, ≤30 mA
- Linearity: ±0.5% of full scale
- Stability: ±0.125% of full scale
- Operating Temp: -18°C to +71°C
- Dimensions (H×W×L): 88.9 × 117 × 241 mm
- Weight: ~2.3 kg (5.0 lb)
Protection: Industrial grade, for harsh turbine environments
Applications
- Power plant steam turbine casing thermal expansion monitoring
- Heavy gas turbine and compressor frame expansion measurement
- Integration with Bently Nevada 3500/40M or 1904 series monitors
Preventive maintenance and machine protection systems
Features & Benefits
- High accuracy LVDT technology for precise displacement readings
- DC-powered, easy integration with standard 24 VDC systems
- Robust stainless steel construction for long-term reliability
- Designed for continuous operation in high-temperature turbine areas
- Direct replacement for older 24765-01-00 models
- Global Inventory: 121 shared inventories worldwide, enabling fast delivery from overseas warehouses.
- Pricing & After-Sales: Competitive prices with reliable 1-year warranty.
Customer Coverage: United States, Germany, Japan, South Korea,
UK, France, Italy, Canada, Brazil, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, Turkey.
- Product Quality: 100% original new, tested before shipment.
- Discounts: Wholesale discounts available for bulk orders.
PLC Module | DCS Module | Industrial Control | Original New | In Stock | Fast Delivery
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos belong to their respective owners. They are used for identification purposes only.
