Woodward 8440-2082 easYgen-3200XT-P1 Genset Controller

Product Description

Woodward 8440-2082 is the front-panel mounted easYgen-3200XT-P1 generator set controller with integrated DynamicsLCD color display, belonging to the easYgen-3000XT series power management platform. It integrates engine control, generator protection, voltage regulation, synchronizing and peer-to-peer paralleling functions. This flush panel version is equipped with local HMI for parameter setup, real-time data viewing, alarm checking and manual operation, widely used for single genset and multi-unit parallel power systems.

Product Functions

• Complete genset auto start/stop, speed control and voltage regulation
• Generator protective functions: over/under voltage, over/under frequency, overcurrent, reverse power
• Automatic synchronizing and load sharing for multi-generator paralleling
• Built-in color touch LCD HMI for local monitoring, configuration and manual control
• Dual CAN ports configurable for J1939 engine communication or CANopen IKD I/O expansion
• Support redundant control, remote monitoring and Modbus communication for SCADA connection

Applications

• Data center, hospital and industrial standby generator power systems
• Multiple genset islanded parallel operation and grid tie backup power
• Marine generator, oil & gas site prime power control
• Commercial building emergency power and peak shaving systems
• Retrofit replacement for legacy Woodward genset controllers
