Woodward 8440-2116A IKD1M Digital I/O Expansion Module

Product Description

Woodward 8440-2116A (IKD1M) is a CAN-bus remote digital I/O expansion module designed for Woodward easYgen series genset controllers, including easYgen-2000, easYgen-3000XT and DTSC-200. It is factory pre-configured with default CAN ID for plug-and-play connection to the first IKD1M on the bus. This module extends discrete input and relay output channels for generator control, protection and annunciator functions, supporting multi-module cascading for larger I/O requirements in standby and paralleling gen-set systems.

Product Functions

• Provide configurable digital discrete inputs and form-C relay output channels
• Communicate with easYgen controller via CAN bus for real-time I/O data exchange
• Each input supports adjustable alarm delay and NO/NC logic configuration
• Relay outputs can be mapped to alarms, trips, breaker control and status indication
• Support up to 4 IKD1M modules connected on one CAN bus after address configuration
• Remote annunciator and auxiliary status collection for engine and generator signals

Applications

• Backup generator set control and alarm annunciator expansion
• Island mode and parallel gen-set systems using easYgen-3000XT
• Engine auxiliary sensor, limit switch and fault signal acquisition
• Remote relay control for circuit breakers, horns and indicator lights
• Marine, industrial and data center standby power control systems
