ABB DSIH75VP 57310290-RD MasterView Operator Keyboard

Product Short Description

DSIH75VP with part number 57310290-RD is ABB MasterView series industrial operator keyboard panel for classic ABB Master / Advanced OCS DCS systems. It serves as a dedicated hardware HMI operating unit for control room stations, providing physical keys for process operation, parameter input, alarm acknowledgement and system navigation. Rated 230VAC, 13VA, front panel meets IP54/IP65 protection grade. This legacy DCS operator panel is discontinued by ABB, available stock are new surplus and fully tested refurbished spare parts for power, pulp & paper and chemical plant control room retrofit replacement.

Product Functions

• Dedicated physical keyboard interface for ABB MasterView DCS operator station, communicates with monitoring host via serial ports
• Multi-function keys for setpoint adjustment, valve operation, alarm confirmation, trend and graphic page switching
• Numeric keypad and directional navigation keys for parameter entry, tag selection and screen cursor control
• Custom dynamic function keys for quick access to plant graphic displays, group alarms and process trend windows
• Built-in power supply unit, supports 230V AC 50/60Hz mains input for control room cabinet installation
• Front panel rugged membrane keys, dust and splash resistant for continuous 24/7 control room operation
• Self-diagnosis on power status and key matrix, hardware fault indication for maintenance troubleshooting
• Multiple serial communication ports for connection with ABB MasterView 320 and related DCS monitoring stations

Application Scenarios

• ABB Master / Advanced OCS distributed control system control room operator consoles
• Thermal power plant, hydro power station process monitoring and control workstation
• Pulp and paper mill, chemical and petrochemical continuous process control room
• Legacy ABB DCS system maintenance, spare replacement and control console upgrade projects
• Marine and onshore industrial automation control system operator workstation retrofit

FAQs

Q1: Which DCS system does DSIH75VP 57310290-RD belong to?
A1: It belongs to ABB MasterView series, compatible with ABB Master and Advanced OCS DCS operator stations.

Q2: What is the power requirement?
A2: 230V AC, 50/60Hz, power consumption 13VA.

Q3: Is this unit still in ABB active production?
A3: No, this is an obsolete legacy operator keyboard, supplied as surplus or refurbished spare only.

Q4: Common failure issues?
A4: Membrane keypad wear, individual key no response, serial communication failure, internal power supply burnout, connector pin corrosion.
