ABB 1HSD100909-724 CB-2000 Capacitance Meter

Product Description

1HSD100909-724 is ABB CB-2000 portable capacitance test meter, a professional electrical measuring instrument for on-site maintenance of capacitor banks and power factor correction equipment. It has an LCD display with capacitance measurement range 0~1000µF (max 2000µF), basic accuracy 1.0%. Powered by 100–240VAC universal input, equipped with clip-on current transformer, voltage test leads, rechargeable NiMH battery pack, power adapter, storage case and supporting software USB stick. This handheld tester can perform safe live and de- capacitance measurement for power capacitors, widely used in power substation maintenance, capacitor bank inspection and preventive testing. It is a high precision field service instrument, available stock includes new and calibrated surplus units.

Key Functions

• High-precision capacitance measurement, measuring range 0 ~ 1000µF, extendable up to 2000µF
• 1.0% measurement accuracy, LCD digital readout for direct capacitance value display
• Supports both live-line and de-energized capacitor bank field testing
• Comes with clip-on CT and voltage clips for quick connection to capacitor terminals
• Built-in rechargeable NiMH battery for portable field operation, plus 100-240VAC mains adapter
• Support data export and report generation via PC software for maintenance records
• Portable rugged housing for outdoor substation and industrial site use
• Overvoltage and overcurrent protection for operator safety during field tests

Application Scenarios

• Power substation capacitor bank routine inspection and preventive maintenance
• Industrial plant power factor correction capacitor testing and health assessment
• On-site commissioning and fault diagnosis of reactive power compensation equipment
• Power utility field service, electrical preventive test projects
• Capacitor aging check and replacement evaluation for high voltage power systems

FAQ

Q1: What is the model name of 1HSD100909-724?
A1: The instrument model is CB-2000 capacitance meter, part number 1HSD100909-724.

Q2: What is the maximum capacitance it can test?
A2: Standard measuring range is 0~1000µF, maximum measurable capacitance up to 2000µF.

Q3: Can it test capacitors while the circuit is energized?
A3: Yes, it supports live-line capacitance measurement with the matched clip-on current transformer and voltage probes.

Q4: Common issues?
A4: Battery aging, clip-on CT damage, LCD display fading, test lead wear, calibration drift after long-term field use.
