NI SCXI-1104C Signal Conditioning Module-KIMI
- Part number：SCXI-1104C
- Product Origin：America
- HS CODE：8537109021
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
NI SCXI-1104C 8-Channel Universal Analog Input Signal Conditioning Module
SCXI Series - High-Precision Signal Conditioning for Industrial & Laboratory Data Acquisition
1. Product Overview
The NI SCXI-1104C is an 8-channel universal analog input signal conditioning module from National Instruments' SCXI (Signal Conditioning eXtensions for Instrumentation) series, designed for medium-voltage signal conditioning and high-precision data acquisition when paired with NI DAQ devices. It offers software-selectable 8 differential or 16 single-ended inputs, programmable gain, 10 kHz low-pass filtering, and sensor excitation, enabling direct connection to voltage, current, RTD, and strain gauge sensors without additional signal conditioning. The module supports multiplexing of all inputs to a single DAQ channel, expanding system channel count while ensuring measurement accuracy and noise immunity, making it ideal for industrial automation, automotive testing, aerospace, and laboratory research applications.
Key Specifications
• Model: SCXI-1104C | Brand: National Instruments (NI) | Series: SCXI Signal Conditioning
• Type: 8-Channel Universal Analog Input Signal Conditioning Module
• Input Configuration: 8 Differential (DIFF) or 16 Single-Ended (SE) (Software-Selectable)
• Input Range: ±10V (Voltage), 0-20mA (Current, Built-in 249Ω Precision Shunt Resistor)
• Programmable Gain: 1, 2, 5, 10, 20, 50, 100, 200, 500, 1000 (Software-Configurable)
• Low-Pass Filter: 3-Pole, 10kHz Cutoff Frequency (SCXI-1104C Specific, for Fast-Signal Applications)
• Common-Mode Voltage Range: ±60VDC (Continuous) | Channel Isolation: 500VDC (Continuous)
• CMRR: >100dB @ 60Hz | Input Impedance: 1MΩ (Normal Powered On)
• Sensor Excitation: ±15V / ±15mA (Per Channel, for RTD/Strain Gauge Power)
• Communication: Multiplexed Output to DAQ Device | Compatibility: SCXI-1000/1001/1000DC Chassis
• Power Supply: SCXI Chassis Backplane Power (±15V, +5V) | Typical Power Consumption: 5W
• Operating Temperature: 0°C to +50°C | Storage Temperature: -40°C to +85°C
• Dimensions: 101.6mm (W) × 160mm (D) × 22.9mm (H) | Weight: 300g
• Software Support: LabVIEW, LabWindows/CVI, Measurement Studio, NI-DAQmx Driver
2. Core Features
• 8-Channel Universal Input: Supports differential/single-ended voltage and current signals for multi-sensor integration
• 10kHz Filtering: Three-pole low-pass filter for fast dynamic signal acquisition without 60Hz noise degradation
• High Precision: ±0.01% FS Nonlinearity, 50μV/°C Offset Drift, 20ppm/°C Gain Drift for Stable Measurements
• Programmable Gain: 10 Ranges to Match Sensor Outputs, Eliminating Need for External Amplifiers
• Built-in Sensor Excitation: Per-channel ±15V/±15mA for RTDs, strain gauges, and other active sensors
• Channel Isolation: 500VDC Isolation Prevents Ground Loops and Protects DAQ Systems
• Multiplexed Output: All Channels Multiplexed to One DAQ Input, Expanding System Channel Count
• SCXI Chassis Compatibility: Works with Standard SCXI Chassis for Modular, Scalable Systems
• Software Flexibility: Full Integration with NI Software Ecosystem for Easy Configuration & Data Analysis
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Industrial Automation: Process Monitoring (Pressure, Flow, Temperature) in Manufacturing Lines
• Automotive Testing: Engine Vibration, Powertrain Voltage, and Sensor Signal Acquisition
• Aerospace: Avionics System Testing, Structural Load Monitoring, and Environmental Data Logging
• Laboratory Research: Material Testing, Biomedical Signal Acquisition, and Physics Experimentation
• Energy: Power Grid Monitoring, Battery Testing, and Renewable Energy System Data Collection
4. Installation & Maintenance
Installation: Mount in SCXI Chassis (SCXI-1000/1001/1000DC); Connect Sensors to Front-Panel Terminals; Wire Multiplexed Output to DAQ Device Input; Configure Input Type, Gain, and Filter via NI-DAQmx; Verify Channel Isolation and Signal Integrity.
Maintenance: Daily – Check Chassis Power and Module Status LEDs; Weekly – Calibrate with NI Calibration Tools; Annual – Inspect Terminal Connections, Clean Chassis Fans, and Update DAQmx Firmware.
Safety Notes: Use ESD Protection When Handling; Ensure Channel Isolation is Maintained for High-Voltage Signals; Follow NI Safety Guidelines for SCXI System Configuration.
