NI SCXI-1300 Terminal Block
The NI SCXI-1300 is a high-performance, shielded terminal block designed for seamless integration with National Instruments SCXI signal conditioning modules, serving as a critical interface between field sensors/actuators and SCXI chassis in industrial data acquisition and control systems. Featuring a compact, rack-mountable design with 32 screw terminals, this terminal block simplifies secure wiring connections for analog and digital signals, eliminating the need for complex custom wiring harnesses. Its built-in shielding provides robust protection against electromagnetic interference (EMI) and radio frequency interference (RFI), ensuring signal integrity in harsh industrial environments with high electrical noise. The SCXI-1300 supports a wide range of signal types including low-level voltage signals, thermocouple inputs, and discrete digital signals, making it compatible with a broad spectrum of SCXI modules such as the SCXI-1102, SCXI-1160, and SCXI-1125. With its tool-less mounting mechanism and clear terminal labeling, it enables fast installation, easy maintenance, and straightforward troubleshooting for technicians. Ideal for applications in automated test systems, process monitoring, manufacturing quality control, and research laboratories, the SCXI-1300 enhances system reliability and reduces wiring errors in data acquisition setups.
| Specification Item | Details |
|---|---|
| Product Model | NI SCXI-1300 |
| Product Type | 32-Channel Shielded Terminal Block for SCXI Modules |
| Terminal Configuration | 32 Screw Terminals (2 Rows x 16 Terminals); 0.5 mm² (20 AWG) Max Wire Gauge |
| Shielding Design | Integrated Metal Shield; Terminal-to-Shield Isolation: 500 Vrms |
| Compatible SCXI Modules | SCXI-1102, SCXI-1104, SCXI-1105, SCXI-1106, SCXI-1125, SCXI-1160, SCXI-1162 |
| Supported Signal Types | Analog Input/Output, Digital I/O, Thermocouple, Strain Gauge, Voltage Signals |
| Mounting Type | Direct Mount to SCXI Module Front Panel; Rack-Mount Compatible with SCXI Chassis |
| Operating Temperature | 0°C ~ +55°C (32°F ~ +131°F); Storage Temperature: -20°C ~ +70°C |
| Humidity Tolerance | 10% ~ 90% RH, Non-Condensing |
| Application Scenarios | Industrial Data Acquisition, Automated Test Systems, Process Monitoring, Manufacturing Quality Control, Laboratory Research |
Important Note: The NI SCXI-1300 terminal block must be paired with compatible SCXI signal conditioning modules to ensure proper signal transmission and system functionality. When wiring, ensure that the wire gauge does not exceed the terminal's maximum rating (0.5 mm² / 20 AWG) and that all connections are securely tightened to prevent signal loss or intermittent contact. The integrated shield should be properly grounded according to NI installation guidelines to maximize EMI/RFI protection. For detailed wiring diagrams, module compatibility lists, and installation instructions, please refer to the official National Instruments product documentation or contact NI technical support.
