Lam Research 810-800060-001 Semiconductor Equipment PCB Assembly

Product Description
810-800060-003 is a printed circuit board assembly manufactured by Lam Research, designed for Lam plasma etch semiconductor wafer processing tools. This VME form factor interface board is installed in the equipment main controller chassis. It handles digital and analog signal routing, real-time command transmission and status feedback between the main CPU and multiple subsystems, including gas panel, vacuum monitoring and chamber actuator control. The PCB assembly is fully populated with electronic components, manufactured under strict ESD control and factory functional burn-in testing. It serves as OEM spare replacement part for semiconductor fab production etch tools.

Key Functions

• VME bus interface for high-speed communication with the main system CPU
• Analog signal conditioning and acquisition from pressure, flow and temperature sensors
• Digital input/output control for pneumatic valves, interlock relays and chamber actuators
• Real-time status collection and fault alarm reporting back to tool host software
• Built-in hardware self-diagnosis for circuit integrity and channel fault detection
• ESD protection and anti-vibration design compliant with cleanroom fab environment
• Standard VME rack slot mounting inside Lam plasma etcher control cabinet
• Pre-assembled PCB assembly for direct swap during on-site maintenance

Application Scenarios

• Lam Research plasma etching wafer processing semiconductor equipment
• Semiconductor cleanroom fab equipment maintenance and spare parts replacement
• Process chamber multi-sensor monitoring and actuator control subsystem
• Fab tool refurbishment, upgrade and spare inventory backup

FAQ

Q: Who manufactures 810-800060-003?
A: Lam Research, USA semiconductor equipment OEM.

Q: What form factor does this PCB use?
A: VME bus card, fits in standard VME rack chassis of Lam etch tools.

Q: What is the main purpose of this assembly?
A: Realize signal collection, actuator control and data communication between main controller and chamber subsystems.
