Lam Research 853-025903-001 Semiconductor Equipment PCB Assembly
  • Warehouse: Spot
  • Warranty: 365 days
  • Quality: Original module
  • Condition: New
  • Shipping method: Courier delivery

  • Contact person: LI MING
  • Contact number: +86 18059884790
  • WeChat:18059884790
  • E-mail: plc66@qq.com

Product Description

Lam Research 853-025903-001 Semiconductor Equipment PCB Assembly

Product Description
853-025903-001 is a printed circuit board assembly manufactured by Lam Research, designed for Lam plasma etch wafer processing semiconductor tools. This PCB assembly acts as a precision interface control board, responsible for signal conditioning, digital I/O control and communication between the main controller and chamber sensors and actuators. Fully assembled with electronic components, it passes strict ESD control and factory burn-in testing. Installed in the equipment control cabinet, it serves as OEM spare replacement component for semiconductor fab production tools.


Key Functions

  • High-precision analog signal acquisition from pressure, temperature and gas flow sensors
  • Digital output control for pneumatic valves, vacuum interlock and chamber auxiliary actuators
  • High-speed data exchange and command communication with the main system controller
  • On-board hardware self-diagnosis for fault detection and status feedback
  • ESD protection and anti-vibration design, compliant with cleanroom fab requirements
  • Standard rack slot mounting inside Lam etcher equipment chassis
  • Pre-assembled PCB for direct replacement during equipment maintenance

Application Scenarios

  • Lam Research plasma etching wafer processing semiconductor equipment
  • Semiconductor cleanroom fab equipment maintenance and spare parts replacement
  • Process chamber monitoring, gas supply and vacuum control subsystem
  • Fab tool refurbishment, upgrade and spare inventory backup

FAQ

Q: Who manufactures 853-025903-001?
A: Lam Research, USA semiconductor equipment OEM.

Q: What equipment is this PCB used for?
A: Lam plasma etch wafer processing tools in semiconductor fabrication plants.

Q: What is the main function of this board?
A: Collect chamber sensor signals, control field actuators and communicate with the main tool controller.
