Bently Nevada 330190-085-01-05 — 3300 XL Extension Cable
The 330190-085-01-05 is a 3300 XL series extension cable
from Bently Nevada (a Baker Hughes business), a leading manufacturer of
machinery protection and condition-monitoring systems. It is a proximity probe
extension cable used to connect a 3300 XL proximity probe to its associated
transducer/前置器 (前置器) signal conditioner, extending the probe’s reach to the monitoring
electronics. The 330190 model number identifies it as an extension cable in the 3300 XL 8 mm / 5 mm probe system family, and the hyphenated suffixes encode
its length, connector type and other options.
- Bently Nevada 3300 XL extension cable
- Connects proximity probe to transducer / signal conditioner
- Part of the 3300 XL 8 mm / 5 mm probe system family
- Suffix codes (085-01-05) encode length and connector options
- For machinery protection & condition monitoring
Key Features & Functions
Proximity Probe Extension
Extends the cable run between a 3300 XL proximity probe and its transducer (前置器), allowing the monitoring electronics to be mounted away from the machine.
3300 XL System Compatibility
Part of the 3300 XL probe system, matching the connectors and electrical characteristics of 3300 XL 8 mm and 5 mm probes.
Industrial-Grade Construction
Built for harsh machine environments, with the cable protection and connectors expected in rotating-machinery instrumentation.
Configurable Options
The -085-01-05 suffix encodes cable length, connector type and other
build options — confirm the exact configuration from the datasheet.
Technical Specifications
| Model Number | 330190-085-01-05 |
|---|---|
| Brand | Bently Nevada (Baker Hughes) |
| Series | 3300 XL |
| Item Type | Extension cable (proximity probe system) |
| Probe Compatibility | 3300 XL 8 mm / 5 mm probe system |
| Cable Length Option | 085 (encode per datasheet) |
| Connector / Option Codes | 01, 05 (per datasheet) |
Source note: The 330190 model is confirmed as an extension cable in Bently
Nevada’s 3300 XL series. Important caution: the Bently Nevada 3300 XL
system requires a matching total system length (probe + extension cable)
— typically 5 m or 9 m — for correct calibration. The exact length represented by the -085 suffix, and the precise meaning of the -01 and -05
option codes, were not confirmed from an official datasheet and must be
verified before ordering or replacing.
Typical Application Scenarios
- Rotating Machinery Monitoring: connecting proximity probes on turbines, compressors, pumps and motors to their monitoring systems.
- Machinery Protection Systems: part of the probe-to-monitor signal chain in plant protection systems.
- Condition Monitoring: supporting vibration and shaft-displacement measurement.
- Legacy System Maintenance: keeping existing 3300 XL installations running with correct spare cables.
- Spare Part Replacement: replacing extension cables in the field.
Frequently Asked Questions
What is the Bently Nevada 330190-085-01-05?
It is an extension cable from Bently Nevada’s 3300 XL series, used to connect a 3300 XL proximity probe to its transducer / signal conditioner.
Is it a B&R part?
No — this is a Bently Nevada (Baker Hughes) part, not B&R. Bently Nevada makes machinery protection and condition-monitoring equipment, a different product domain from the B&R automation modules in this list.
Why does the system length matter?
Bently Nevada 3300 XL systems are calibrated for a specific total length (probe + extension cable), commonly 5 m or 9 m. Using the wrong cable length can affect measurement accuracy — always match the system length specified for your installation.
Is “330190-085-01-05” the full part number?
Yes as given, but verify the exact string and each suffix segment against the datasheet, as the hyphenated codes define length and connector options.
Where can I find the official datasheet?
Official technical documentation is available from Bently Nevada (Baker Hughes) and authorized distributors. Verify all specifications there before purchase.
