1900/65A-01-03-00-01 Bently Nevada General Purpose Equipment Monitor

Product Description

1900/65A-01-03-00-01 is Bently Nevada standalone machinery condition monitor, powered by 110–220V AC 50/60Hz external power supply. This variant is equipped with remote display with 10’ unassembled PVC cable, DIN rail mounting type, no hazardous area certification, and built-in Modbus RTU communication interface. It features 4 transducer input channels for vibration, displacement or speed signals and 4 RTD temperature channels for continuous condition monitoring of rotating and reciprocating plant equipment. It supports relay alarm/trip outputs and 4-20mA analog outputs to transmit measurement data to DCS, PLC or recorder systems, and realizes remote data reading and parameter configuration via Modbus network.

Product Features & Functions

• 4 configurable transducer inputs, compatible with proximity probes, accelerometers and velocity sensors
• 4 RTD temperature channels for bearing, stator and casing temperature monitoring
• 110–220V AC universal power supply with external power unit
• Remote display with 10-foot unassembled PVC cable for flexible on-site installation
• DIN rail mounting design for installation inside standard industrial control cabinets
• Built-in Modbus RTU communication for remote data access and configuration
• 6 programmable SPDT relay outputs for alert and danger alarm/trip functions
• 4 isolated 4-20mA analog outputs for connecting to DCS, PLC or chart recorders
• Onboard 200-event history log to record alarms, trips and diagnostic events
• Sensor fault diagnostics to detect open circuit, short circuit and transducer failure
• Configurable signal filters, alarm thresholds and time delays via local display or PC software
• Front panel LED indicators for power, alarm and trip visual status check

Application Scenarios

• Vibration and temperature monitoring for pumps, fans, blowers and small compressors
• Auxiliary rotating equipment monitoring in power plants, water treatment and cement factories
• Petrochemical, refinery and pulp & paper plant balance-of-plant machinery protection
• Automation system integration requiring Modbus data upload to host control system
• Retrofit and spare replacement of Bently Nevada 1900 series standalone monitoring systems

FAQ

Q: What does suffix 01-03-00-01 mean?
A: 01 = 110–220V AC power; 03 = remote display with 10’ unassembled PVC cable; 00 = DIN rail mount, no hazardous area approvals; 01 = Modbus RTU communication interface.

Q: What is the advantage of this model compared to versions without communication?
A: It supports Modbus RTU, which allows real-time measurement values, alarm status and fault information uploaded to DCS/PLC for centralized plant monitoring.

Q: Is 1900/65A series still in production?
A: The 1900/65A series is still active by Bently Nevada (Baker Hughes). Original new units are available via authorized distributors.
