1. Product Description

The SPHSS13 is a dedicated hydraulic servo submodule developed by ABB for the Bailey Symphony / INFI 90 distributed control system (DCS) platform, manufactured in Sweden. It acts as a critical signal conversion and closed-loop control bridge between DCS digital controllers and field electro-hydraulic servo valves, I/H converters and hydraulic actuators.

Core physical specs: Single-slot rack-mounted design, dimension 297.18 × 35.56 × 175.26 mm, weight 0.272kg, 24VDC operating power supply, 50kHz high-frequency control output, IP20 cabinet protection rating.

This module supports LVDT linear position sensor feedback, converts digital valve position setpoints from the DCS controller into proportional analog drive current for hydraulic servo valves, and forms a fully closed position control loop. It supports redundant DCS rack deployment for power plant critical equipment, complies with IEC industrial control safety standards, and is compatible with Symphony Plus engineering workstation configuration tools.

2. Core Product Functions

• Closed-Loop Valve Position Control: Receives digital position commands from DCS HR controllers, outputs proportional current signals to drive hydraulic servo valves; reads real-time valve stem position via LVDT sensors to eliminate position deviation, achieving precise 0.1% positioning accuracy.
• LVDT Signal Conditioning & Demodulation: Built-in high-precision excitation and demodulation circuit for linear variable differential transformers, filters signal noise and converts analog displacement signals into digital values for DCS backplane transmission.
• Manual/Auto Switch Control: On-board manual bypass mode for on-site valve calibration and maintenance; automatic mode for continuous DCS remote process regulation, with bumpless mode switching without valve jitter.
• High-Speed Dynamic Response: 50kHz control loop bandwidth, fast response to transient process fluctuations, suitable for turbine anti-surge and fast valve adjustment scenarios.
• Multi-Loop Interlock & Fault Diagnosis: Real-time monitoring of LVDT open/short circuit, servo valve drive overload, module power undervoltage; records fault codes and uploads alarm data to DCS operator stations.
• Redundant System Compatibility: Supports hot-standby redundant rack architecture, seamless master/backup module switchover without valve position loss during single module failure.
• On-Board Calibration Logic: Zero and span calibration parameters stored in non-volatile memory, adjustable via Symphony engineering workstation without external signal generators.
• Isolated Signal Circuit Design: Galvanic isolation between DCS digital bus and field hydraulic analog circuits, eliminates ground loop interference from high-power hydraulic equipment.

3. Typical Application Scenarios

• Thermal Power Plant Turbine Governing Systems: Control main steam throttle valves, control valves, fuel gas valves, and turbine inlet guide vanes for steam/gas turbines, stabilize unit speed and load output.
• Oil & Gas Compressor Anti-Surge Control: Regulate compressor recycle hydraulic valves to prevent surge damage under variable flow working conditions.
• Petrochemical Process Pressure Regulation: Precision control of hydraulic regulating valves in reactor, distillation tower and tank farm process loops.
• Hydroelectric Power Unit Governor: Drive hydraulic wicket gate actuators to adjust water flow and generator output frequency.
• Pulp & Paper Mill Hydraulic Actuators: Control paper machine calender and tension roll hydraulic positioning valves.
• Heavy Industry Metallurgical Furnace Valves: Adjust furnace air supply and flue gas hydraulic dampers for temperature control.
• Power Plant Safety Trip Systems: Critical emergency shutdown hydraulic valve actuation control with redundant SPHSS13 module backup.
