The ABB 500AIM02 (order code: 1MRB150022R0002) is an 8‑channel differential analog input module designed for ABB AC500 series PLC/DCS, optimized for high‑precision acquisition of industrial process signals (temperature, pressure, flow, level). As a variant of the 500AIM02 base model (1MRB150022R001), it retains identical core specs—16‑bit ADC, channel‑to‑channel isolation (2.5kV), ABB FBP (Flexible Bus Protocol) integration—with minor batch/component variations for supply chain flexibility. It features IP20 front protection, -20°C to +70°C operation, surge protection, EMC filtering, and isolated sensor excitation, ensuring stable performance in harsh industrial sites (chemical plants, power stations, manufacturing lines).

• Input Channels: 8 differential; software‑configurable per channel (no hardware changes)            • Signal Types: 4‑20mA; 0‑10V; ±10V; Type J/K/T/E/R/S/B/N thermocouples            • Accuracy & Speed: 16‑bit resolution; ±0.05% full‑scale accuracy; 10ms max conversion time            • Protection: 2.5kV channel isolation; 1kV channel‑to‑ground isolation; surge/overvoltage/overcurrent protection

• Integration: ABB FBP protocol; AC500 CPU/coupler compatible; distributed I/O expansion            • Mounting: 35mm DIN rail; 120×100×65mm dimensions; control cabinet installation            • Power Supply: 24V DC redundant input (18‑30V); reverse polarity protection; isolated 5V sensor excitation            • Diagnostics: Front‑panel LEDs; non‑volatile fault logging; channel‑level alarm reporting
