Vibro-meter 200-560-000-018 200-560-101-015 I/O Module--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

Vibro-meter (Meggitt) 200-560-000-018 & 200-560-101-015 VM600 IOC4T 4-Channel I/O Module

Integrated I/O Card for VM600 Machinery Protection & Condition Monitoring Systems

1. Core Overview

The Vibro-meter 200-560-000-018 and 200-560-101-015 are VM600 IOC4T 4-channel input/output modules (Meggitt Vibro-meter, a Rockwell Automation brand), engineered for machinery protection (MPS) and condition monitoring (CMS) in power generation, oil & gas, and heavy industry. These modules integrate 4 isolated I/O channels for vibration, temperature, and process signal acquisition, paired with 4 output channels for alarms, trip relays, and control signals, serving as a critical interface between field sensors/actuators and the VM600 rack system. With galvanic isolation, built-in diagnostics, and compatibility with MPC4/AMC8 protection cards, they ensure reliable real-time monitoring and safe machinery operation in harsh industrial environments.

• Core Role: 4-channel I/O interface for VM600 MPS/CMS; machinery protection, vibration/temp monitoring, alarm control • Model Info: 200-560-000-018, 200-560-101-015; VM600 IOC4T; Meggitt Vibro-meter original • Key Specs: 4 input + 4 output channels; 24Vdc; -40°C to +70°C; IP20 front; CE/UL certified • Reliability: Galvanic isolation; hot-swappable; LED status indicators; IEC 61010 safety compliant

Vibro-meter 200-560-000-018 200-560-101-015 VM600 IOC4T (5).jpg

2. I/O Channels & Signal Performance

Each IOC4T module offers 4 universal input channels (vibration, temperature, pressure, 4-20mA) and 4 output channels (relay/analog) for control and alarm signaling. Inputs handle 0.1Hz-10kHz frequency ranges, 0-1000mm/s vibration, and 4-20mA process signals with high accuracy, while outputs drive trip relays, alarms, and control valves with 25mA-2A current ratings. Galvanic isolation between channels prevents cross-talk and noise interference, and pre-release capacitance handling (30-3500µF) ensures reliable switching for inductive loads. Built-in diagnostics monitor channel health, with LED indicators for power, fault, and channel status.

• Inputs: 4 channels (vibration/temp/pressure/4-20mA); 0.1Hz-10kHz; 0-1000mm/s; 24Vdc-powered • Outputs: 4 channels (relay/analog); 25mA-2A; 30-3500µF pre-release capacitance; 33kΩ off-state resistance • Isolation: Galvanic isolation (input-output); 2.5kV isolation voltage; noise immunity to 10V/m EMI • Diagnostics: LED status (power/fault/channel active); real-time event logging; VM600 MPSx software integration

Vibro-meter 200-560-000-018 200-560-101-015 VM600 IOC4T (3).jpg

3. VM600 Integration & Communication

The IOC4T modules integrate seamlessly with VM600 racks and MPC4/AMC8 protection cards, supporting "One-Shot" configuration via Ethernet/RS-232 using MPSx software. They feature dual Ethernet ports and up to 3 serial connections (RS-232/422/485) for Modbus RTU/TCP or PROFINET communication, enabling data exchange with SCADA/DCS systems. Hot-swappable design allows online maintenance without system shutdown, and front-panel AR (Alarm Reset) buttons enable quick alarm management. The modules are powered by the VM600 backplane (24Vdc), eliminating external power supplies and simplifying installation.

• Integration: VM600 rack-compatible; MPC4/AMC8 protection card support; "One-Shot" configuration via MPSx software • Communication: Dual Ethernet; 3 serial (RS-232/422/485); Modbus RTU/TCP, PROFINET; SCADA/DCS connectivity • Installation: Hot-swappable; VM600 backplane-powered (24Vdc); front-panel AR button; screw-terminal wiring • Software: VM600 MPSx configuration; real-time data logging; remote monitoring/troubleshooting

Vibro-meter 200-560-000-018 200-560-101-015 VM600 IOC4T (4).jpg

Typical Applications & Compliance

Key Sectors: Power generation (turbines/generators), oil & gas (compressors/pumps), petrochemical, pulp & paper, mining.

Use Cases: Machinery protection (ESD/F&G), vibration monitoring, temperature/pressure process control, alarm/trip systems.

Compliance: IEC 61010, CE, UL 508, RoHS; industrial EMC (IEC 61000); -40°C to +70°C operating temp.

Spare Part Grade: Meggitt Vibro-meter original; factory-tested for VM600 compatibility; 1-year standard warranty.

Vibro-meter 200-560-000-018 200-560-101-015 VM600 IOC4T (1).jpg

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

Technical Documentation | Vibro-meter 200-560-000-018/200-560-101-015 | VM600 IOC4T 4-Channel I/O Module for Machinery Protection
