VIBRO-METER MPC4 200-510-078-115 Protection Card--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

VIBRO-METER (Meggitt) MPC4 200-510-078-115 Machinery Protection Card

1. Core Product Overview

The VIBRO-METER MPC4 200-510-078-115 is a 4‑channel dynamic protection card for Meggitt VM600 machinery protection systems, designed for real‑time monitoring and protection of critical rotating equipment (turbines, generators, compressors, pumps). It integrates 4 individually programmable dynamic channels (displacement/velocity/acceleration) and 2 speed channels, supporting eddy‑current proximity probes, IEPE accelerometers, and velocity sensors, with DSP‑based signal processing (0.1 μm / 0.1 mA resolution, ±0.05% accuracy). The card enables Alert/Danger setpoints, overspeed/underspeed protection, and order‑tracking phase monitoring, triggering relay outputs for alarms/shutdowns per API 670 standards. It uses VM600 rack power (+5V DC / ±12V DC), supports Modbus/CAN communication, and is hot‑swappable for 24/7 reliability in -40°C~+85°C industrial environments.

• Core Role: Rotating machinery protection; shaft vibration/displacement/speed monitoring; alarm/shutdown triggering; API 670 compliance • Model Info: 200-510-078-115 (MPC4); Meggitt VIBRO-METER; VM600 system compatible; 4‑dynamic + 2‑speed channels • Key Specs: ±0.05% accuracy; 0.1 μm / 0.1 mA resolution; Modbus/CAN; -40°C~+85°C; hot‑swappable • Reliability: Redundant power; hot‑swap; fault relay; API 670; IEC 61508 (SIL 2 optional); IP20 rack mount

VIBRO-METER MPC4 200-510-078-115（1）.jpg

2. Key Technical Specifications

Parameter	Specification
Channels	4 dynamic (displacement/velocity/acceleration); 2 speed (tachometer/keyphasor)
Sensors	Eddy‑current (2mm max gap); IEPE accelerometers (100mV/g); velocity (0.1‑100 mm/s)
Accuracy & Resolution	Accuracy: ±0.05% ±1 LSB; Resolution: 0.1 μm (displacement), 0.1 mA (current)
Power Supply	VM600 rack: +5V DC (12.5W typ.), ±12V DC (2.5W max); 1W per sensor
Communication	Modbus RTU/TCP; CAN bus; 4‑20mA analog outputs (4 channels); 2 relay outputs (NO/NC, 2A/24V DC)
Performance	Filtering: 0.1Hz‑10kHz (programmable); Update rate: 100Hz; Overspeed: 1‑100,000 RPM
Environment	-40°C~+85°C; 5‑95% non‑condensing; IEC 60068‑2‑6 vibration
Mechanical	6U rack (262×20×187mm); 0.4 kg; hot‑swappable; IP20

3. Monitoring & Protection Logic

The MPC4 uses a 32‑bit DSP for real‑time signal processing: 4 dynamic channels measure peak‑to‑peak/peak/RMS amplitude with programmable broadband/narrow‑band filters (0.1Hz‑10kHz), while 2 speed channels track RPM and keyphasor phase for order tracking. It supports Alert/Danger setpoints (0.01‑1000 μm), overspeed (1‑100,000 RPM), underspeed, and bearing temperature monitoring, triggering 2 relay outputs (NO/NC, 2A/24V DC) for alarms/shutdowns. Front‑panel LEDs (Power: green; Channel Active: amber; Alarm: blue; Fault: red) and a fault relay enable on‑site/remote monitoring, with event logging (1000 events) for post‑trip analysis.

• Monitoring: Shaft vibration/displacement; casing vibration; speed/phase; bearing temperature; order tracking • Protection: Alert/Danger thresholds; overspeed/underspeed; relay trip; fault logging; API 670 compliance • Signal Processing: DSP filtering; peak/RMS/peak‑to‑peak; order tracking; adaptive thresholds • Diagnostics: LEDs; fault relay; event log; Modbus/CAN remote monitoring; VM600 system integration

VIBRO-METER MPC4 200-510-078-115（4）.jpg

3. Communication Protocols & Configuration

The MPC4 200-510-078-115 integrates with DCS/SCADA via Modbus RTU/TCP and CAN bus, offering 4‑20mA analog outputs for direct controller interface. Configuration uses the **VM600 Engineering Tool** (Windows) for channel setup, filter parameters, setpoints, and firmware updates, with front‑panel DIP switches for basic addressing. It supports hot‑swap in VM600 racks, preserving config during replacement, and integrates with VM600 IOC4T transducer cards for buffered raw sensor inputs. It also features sensor power (24V DC, 1W per sensor) and cross‑channel monitoring for redundancy.

• Protocols: Modbus RTU/TCP; CAN bus; 4‑20mA analog; relay outputs • Configuration: VM600 Engineering Tool; DIP switches; config backup/restore; hot‑swap retention • Integration: VM600 IOC4T; DCS; SCADA; HMI; safety systems (SIL 2 optional) • Remote Access: Modbus/CAN diagnostics; event log download; firmware updates via TCP/IP

VIBRO-METER MPC4 200-510-078-115（2）.jpg

4. System Integration & Industrial Applications

The MPC4 mounts in VM600 6U racks (19‑inch) with plug‑in terminals for power, sensor inputs, and outputs, integrating with VM600 IOC4T transducer cards and DCS/SCADA via Modbus/CAN. It is ideal for power generation (thermal/hydro/wind), oil & gas, petrochemical, and water/wastewater—where API 670‑compliant rotating machinery protection is critical. It complies with API 670, IEC 61508 (SIL 2 optional), CE, UL, and ATEX Zone 2 (optional conformal coating), with a 12‑month Meggitt warranty and global technical support.

• Integration: VM600 system; IOC4T transducer cards; DCS; SCADA; HMI; safety systems • Mounting: VM600 6U rack; plug‑in terminals; IP20; 19‑inch cabinet • Certifications: API 670; IEC 61508 (SIL 2); CE; UL; ATEX Zone 2 (optional) • Applications: Turbines; generators; compressors; pumps; fans; API 670 critical machinery

5. Installation, Maintenance & Troubleshooting

Installation: VM600 6U rack mounting; sensor wiring (eddy‑current/IEPE/velocity); power (+5V/±12V); DIP switch addressing; LED verification (Power=green).

Configuration: Engineering Tool for channels/filters/setpoints; backup config; integrate with VM600 system.

Maintenance: 6‑month visual inspection; 12‑month sensor calibration; fault diagnosis via LEDs/Engineering Tool; hot‑swap replacement.

Troubleshooting: Red Fault LED = power/sensor/overtemp; check power first; verify sensor continuity; use Engineering Tool for fault codes.

Replacement: Hot‑swap in VM600 redundant racks; plug‑and‑play with pre‑saved config for minimal downtime.
