Vibro-meter (Meggitt) 200-570-000-014 & 200-570-101-013 VM600 RLC16 Relay Card & Backplane Connector

16-Channel Relay Output Module for VM600 Machinery Protection & Condition Monitoring Systems

1. Core Overview

The Vibro-meter 200-570-000-014 is an RLC16 16-channel relay output card, and 200-570-101-013 is its dedicated backplane connector, both designed for Meggitt Vibro-meter VM600 machinery protection (MPS) and condition monitoring (CMS) systems. As a critical output interface, the RLC16 delivers 16 independent relay channels for alarm/trip signaling, emergency shutdown (ESD), and control valve actuation in power generation, oil & gas, and heavy industrial sectors. It integrates with VM600 racks and MPC4/AMC8 protection cards, featuring hot-swappable design, galvanic isolation, and real-time diagnostics to ensure reliable operation in harsh industrial environments. The backplane connector ensures stable power and communication links with the VM600 system, supporting "One-Shot" configuration via MPSx software.

• Core Role: 16-channel relay output for VM600 MPS/CMS; alarm/trip control, ESD, machinery protection • Model Pair: 200-570-000-014 (RLC16 module); 200-570-101-013 (backplane connector); VM600 RLC16 Series • Key Specs: 16 SPST/SPDT relays; 24Vdc; -40°C to +70°C; IP20 front; CE/UL/IEC 61010 certified • Reliability: Galvanic isolation; hot-swappable; LED status indicators; 2.5kV isolation voltage

Vibro-meter 200-570-000-014 200-570-101-013 VM600 (5).jpg

2. Relay Channels & Output Performance

Each RLC16 module is equipped with 16 independent SPST/SPDT relays, each rated for 2A @ 250Vac/30Vdc, supporting inductive/capacitive loads with pre-release capacitance handling (30-3500µF). Galvanic isolation between channels and from the VM600 backplane prevents noise interference and cross-talk, while individual LED indicators show relay status (energized/fault) for quick troubleshooting. The module supports NAMUR-compliant relay functionality, remote alarm reset, and fault history logging, integrating with VM600 MPSx software for real-time event monitoring and configuration.

• Relay Configuration: 16 SPST/SPDT channels; 2A @ 250Vac/30Vdc per relay; 30-3500µF pre-release capacitance • Isolation: Galvanic isolation (channel-to-channel/backplane); 2.5kV isolation voltage; 10V/m EMI immunity • Diagnostics: Individual LED status; real-time event logging; MPSx software integration; remote troubleshooting • Control Features: NAMUR-compliant; remote alarm reset; fault history; ESD/trip signal prioritization

Vibro-meter 200-570-000-014 200-570-101-013 VM600 (1).jpg

3. VM600 System Integration & Installation

The RLC16 module installs in the rear of VM600 racks, using the 200-570-101-013 backplane connector for power and communication with the VM600 system. It is powered by the VM600 backplane (24Vdc), eliminating external power supplies, and supports hot-swappable replacement without system shutdown to minimize process downtime. Integration with MPC4/AMC8 protection cards enables coordinated alarm/trip logic, while dual Ethernet and serial ports (RS-232/422/485) facilitate data exchange with SCADA/DCS via Modbus RTU/TCP or PROFINET protocols. Front-panel AR (Alarm Reset) buttons allow quick on-site alarm management, and "One-Shot" configuration via MPSx software streamlines setup.

• System Compatibility: VM600 racks; MPC4/AMC8 protection cards; MPSx configuration software • Communication: Dual Ethernet; 3 serial ports (RS-232/422/485); Modbus RTU/TCP, PROFINET; SCADA/DCS connectivity • Installation: Rear-mounted in VM600 racks; 200-570-101-013 backplane connector; hot-swappable; backplane-powered (24Vdc) • Configuration: "One-Shot" setup via MPSx; pre-built logic for alarm/trip; seamless I/O mapping with VM600 system

Vibro-meter 200-570-000-014 200-570-101-013 VM600 (4).jpg

Typical Applications & Industrial Compliance

Key Sectors: Power generation (turbines/generators), oil & gas (compressors/pumps), petrochemical, mining, pulp & paper.

Use Cases: Machinery protection (ESD/F&G), vibration/temperature alarm control, critical process trip systems, remote equipment monitoring.

Compliance: IEC 61010, CE, UL 508, RoHS; industrial EMC (IEC 61000); -40°C to +70°C operating temperature.

Spare Part Grade: Meggitt Vibro-meter original; factory-tested for VM600 compatibility; 1-year standard warranty.

Vibro-meter 200-570-000-014 200-570-101-013 VM600 (3).jpg

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.
