ABB REF620E_F NBFNAANNNCC1BNN1X Feeder Protection & Control Relay
All - in - One Microprocessor - Based Relay for Medium - Voltage Feeder Protection & Substation Automation (Relion® 620 Series)
1. Core Overview
The REF620E_F NBFNAANNNCC1BNN1X is a microprocessor - based feeder protection and control relay belonging to ABB's Relion® 620 product series, specially designed for medium - voltage (MV) feeder protection, control, measurement and supervision in utility and industrial power distribution systems. It integrates multiple functions in one compact unit, applicable to radial, looped and meshed networks with or without distributed power generation, featuring a withdrawable plug - in design for rapid installation, commissioning and maintenance.
• Core Role: MV feeder protection, control, measurement and supervision; substation automation integration
• Key Specs: 24 - 250 V AC/DC power supply; -25°C to +55°C operating temperature; IP20 protection grade
• Model Info: REF620E_F (base model); Ordering Code: NBFNAANNNCC1BNN1X; Relion® 620 series member
2. Protection & Control Functions
This relay is equipped with a high - performance industrial - grade processor and advanced algorithms, providing comprehensive protection functions such as overcurrent, earth fault (with high - sensitivity multifrequency admittance - based detection), overvoltage, undervoltage, frequency deviation and arc flash protection. It supports control functions including auto reclosing, load shedding, synchronization and circuit breaker control, and can quickly locate short - circuit and earth - fault points for efficient fault isolation. The protection logic is configurable, and users can tailor the settings according to specific application requirements to ensure the safe and reliable operation of the feeder system.
• Protection Functions: Overcurrent, earth fault, overvoltage, undervoltage, frequency, arc flash, etc.
• Control Functions: Auto reclosing, load shedding, synchronization, circuit breaker remote control
• Fault Detection: Multifrequency admittance - based earth - fault algorithm; precise fault location
