ABB PCD235B1101 (3BHE032025R1101) Control Module
Core Main Control Unit for ABB PCS6000 Medium & High Voltage Drive Systems
1. Module Core Overview
The ABB PCD235B1101 (3BHE032025R1101) is the high-performance main control core module exclusively designed for ABB PCS6000 medium and high voltage drive systems, serving as the central processing and logic control unit for HV/MV frequency converters in industrial power conversion applications. It integrates advanced digital signal processing, real-time drive control algorithms, and multi-channel communication interfaces, enabling precise regulation of motor speed, torque and power output, while supporting redundant operation and comprehensive fault diagnosis to ensure the stable and reliable operation of PCS6000 drive systems in harsh industrial environments.
• Core Role: Main control unit for ABB PCS6000 HV/MV drive systems; central logic & drive algorithm execution
• Key Specs: 24 V DC nominal power supply; industrial-grade DSP core; compact PCB design; IP20 protection grade
• Part Code: PCD235B1101 (Ordering Code: 3BHE032025R1101); ABB PCS6000 dedicated spare part
2. Core Performance & Drive Control Capabilities
PCD235B1101 is built with an industrial-grade high-speed DSP and FPGA chipset, preloaded with ABB's proprietary PCS6000 drive control algorithms, supporting high-precision vector control, direct torque control (DTC) and V/f control modes to adapt to different industrial motor load requirements. It features real-time data acquisition and processing of drive system parameters (voltage, current, temperature, speed), with microsecond-level control response to realize smooth adjustment of HV/MV drive output. The module integrates multi-level fault detection and protection logic, which can quickly identify overvoltage, overcurrent, overheating, short circuit and other faults, and trigger protective actions to avoid drive system damage.
• Control Modes: Support ABB DTC direct torque control, vector control, V/f open-loop control
• Signal Processing: High-speed DSP+FPGA; real-time acquisition of HV/MV drive system electrical & physical parameters
• Fault Protection: Overvoltage/overcurrent/overheat/short circuit protection; real-time fault diagnosis & alarm output
• Operation Stability: Industrial-grade component selection; anti-vibration & anti-interference design for industrial sites
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
Sales Manager: KI MI
WeChat: 18059884790
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Communication & PCS6000 System Integration
The PCD235B1101 integrates a full set of communication interfaces matching the ABB PCS6000 system architecture, including internal high-speed bus for interconnection with drive power modules, I/O modules and monitoring modules, as well as standard industrial fieldbus interfaces for seamless communication with upper-level DCS/PLC systems and HMI touch screens. It supports redundant bus communication to ensure no loss of control and monitoring data, and is fully compatible with ABB PCS6000 drive system configuration software for online parameter adjustment, program upgrade and fault diagnosis. The module features a plug-and-play design for easy replacement and maintenance, minimizing drive system downtime.
• Internal Communication: High-speed dedicated bus for PCS6000 power/IO/monitoring module interconnection
• Fieldbus: Standard industrial bus interfaces; compatible with upper-level DCS/PLC/HMI systems
• Redundancy: Support redundant bus communication; ensure control data integrity and reliability
• Maintenance: Plug-and-play design; online parameter configuration & program upgrade; easy spare part replacement
Typical Applications & Industrial Compliance
Key Applications: ABB PCS6000 medium/high voltage drive systems for power generation, metallurgy, mining, petrochemical, water supply and drainage, cement and other industries; HV/MV motor speed regulation & energy-saving control.
System Compatibility: Exclusively matched with ABB PCS6000 HV/MV drive series; fully compatible with all PCS6000 configuration and monitoring software.
Industrial Compliance: CE certified; meets IEC 61800 drive system standards; industrial EMC/anti-interference compliance (IEC 61000);
Spare Part Grade: ABB original genuine spare part; strict quality control & industrial-grade reliability testing.
