500BIO01 1MRB150005R0001 Mixed Digital I/O Module--KIMI

Part number：500BIO01 1MRB150005R0001
Product Origin：Sweden
HS CODE：8708299000
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB 500BIO01 (1MRB150005R0001) 16DI/16DO Mixed Digital I/O Module

Compact Mixed Digital I/O for ABB AC500 PLC/DCS Industrial Automation & Process Control

1. Core Product Overview

The ABB 500BIO01 (order code: 1MRB150005R0001) is a high-performance 16-input/16-output mixed digital I/O module exclusively engineered for ABB AC500 series PLC/DCS systems, optimized for compact industrial discrete signal acquisition and switching control in space-constrained control cabinets. As a key member of ABB’s 500 series I/O product line, it integrates opto-isolated digital inputs, transistor-based digital outputs, ABB FBP (Flexible Bus Protocol) for plug-and-play integration, and industrial-grade EMC/surge protection. With IP20 front panel protection, -20°C to +70°C wide operating temperature range and channel-to-channel isolation, it ensures stable and reliable operation in high-interference industrial environments such as chemical plants, power stations, manufacturing production lines and building automation systems.

• Core Role: 16DI/16DO mixed digital signal processing; compact I/O expansion; AC500 PLC/DCS discrete control; sensor acquisition & actuator drive • Model Info: 500BIO01 (base model); 1MRB150005R0001 (ABB official order code); 500 series mixed digital I/O module • Key Specs: 16×24V DC opto-isolated DI; 16×24V DC transistor DO; 1ms DI response; 2.5kV isolation; IP20 protection • Reliability: EMC/surge protection; opto-isolation; 24V DC redundant power; anti-vibration (5-50Hz); low power consumption

500BIO01 1MRB150005R0001 (1).jpg

2. Digital I/O Performance & Protection

The 500BIO01 1MRB150005R0001 features 16 independent 24V DC opto-isolated digital input channels (supporting sinking/sourcing, software-configurable) and 16 high-speed 24V DC transistor digital output channels (sourcing type, 0.5A per channel), compatible with most industrial NPN/PNP sensors, limit switches, contactors and small actuators. It delivers 1ms ultra-fast DI response time for real-time industrial control, with 2.5kV channel-to-channel isolation and 1kV channel-to-ground isolation to eliminate cross-talk and ground loop interference. Each channel is equipped with overvoltage (up to 35V DC) and surge protection (IEC 61000-4-5), and 50Hz/60Hz noise filtering to suppress power line interference, ensuring accurate signal acquisition and stable switching even in harsh industrial environments.

• Digital Inputs: 16 channels; 24V DC; opto-isolated; sinking/sourcing (software configurable); 1ms response time • Digital Outputs: 16 channels; 24V DC transistor (sourcing); 0.5A per channel; 100kHz switching speed; short-circuit protection • Isolation & Protection: 2.5kV channel-to-channel; 1kV channel-to-ground; 35V DC overvoltage protection; IEC 61000-4-5 surge protection • Compatibility: NPN/PNP sensors; limit/proximity switches; push buttons; small contactors; indicator lamps; mini actuators

500BIO01 1MRB150005R0001 (6).jpg

3. AC500 PLC/DCS Integration & Installation

The 500BIO01 adopts ABB FBP (Flexible Bus Protocol) for seamless plug-and-play integration with all ABB AC500 series CPUs (e.g., PM564-TS, PM583-ETH, PM590-ETH) and expansion couplers (500SCM01), supporting distributed I/O topologies (tree/star) for large-scale automation system expansion with minimal cabinet space. It features standard 35mm DIN rail mounting with an ultra-compact form factor (100×100×65mm), fitting into small industrial control cabinets and distributed I/O enclosures. The front-panel LED indicators provide real-time status for power, module operation and each I/O channel (ON/OFF), and non-volatile fault logging records up to 100 historical events (short circuit, overvoltage, module fault) for quick troubleshooting. The module is powered by 24V DC redundant input (18-30V DC) with reverse polarity protection, ensuring uninterrupted operation in industrial applications.

• Protocol & Compatibility: ABB FBP; fully compatible with AC500 CPUs/couplers; distributed I/O expansion support • Mounting: 35mm standard DIN rail; 100×100×65mm ultra-compact dimensions; small cabinet/distributed I/O enclosure compatible • Power Supply: 24V DC redundant input (18-30V); reverse polarity protection; low power consumption (<5W) • Diagnostics: Front-panel LED (power/module/32 I/O channels); non-volatile fault logging; remote status feedback to AC500 CPU

500BIO01 1MRB150005R0001 (5).jpg

Typical Applications & Compliance

Key Sectors: Industrial process control (chemical/petrochemical/cement); power generation (thermal/hydro/wind); manufacturing (automotive/electronics); water/wastewater treatment; building automation; mining machinery; packaging equipment.

Use Cases: Compact discrete signal monitoring & control; distributed I/O expansion; production line interlock control; sensor data collection & small actuator drive; equipment on/off status detection & alarm triggering; AC500 PLC/DCS mixed digital I/O expansion.

Industrial Compliance: IEC 61131-2 (industrial control equipment); IEC 61010-1 (electrical safety); IEC 61326-1 (EMC); CE/UL/RoHS certified; -20°C to +70°C operating temperature; IP20 front panel protection.

Spare Part Grade: ABB genuine original module; factory-tested for vibration/EMC/thermal performance; 12-month standard warranty; compatible with all AC500 system firmware versions; direct replacement for legacy AC500 mixed I/O modules.

500BIO01 1MRB150005R0001 (2).jpg
