CS513 3BSE000435R1 Communication Module-KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB CS513 3BSE000435R1 IEEE 802.3 LAN Communication Module (MasterBus 300E)
Advant OCS Series - High-Speed LAN Communication for Distributed Control & Real-Time Data Exchange
1. Product Overview
The ABB CS513 (Ordering Code: 3BSE000435R1) is an IEEE 802.3 LAN communication module (MasterBus 300E) belonging to the Advant OCS series, specifically designed for ABB Advant Controller 410/450/450RMC and Advant Master distributed control systems (DCS). As a core component for industrial network communication, it enables high-speed data exchange between DCS controllers, field instruments, HMIs, and third-party systems, supporting both MB300 (standard) and MB300E (extended) protocols with switch-selectable modes, and IEEE 802.3 Ethernet for 10Mbps data transmission. Equipped with built-in diagnostics, fault detection, and hot-swap support, it ensures reliable communication in process control, power generation, oil & gas, and manufacturing industries, minimizing downtime and enhancing system scalability.
Key Specifications
• Model: CS513 | Ordering Code: 3BSE000435R1 | Brand: ABB | Series: Advant OCS
• Compatibility: ABB Advant Controller 410/450/450RMC, Advant Master DCS, Industrial Ethernet Networks
• Type: IEEE 802.3 LAN Communication Module (MasterBus 300E)
• Protocols: MasterBus 300 (MB300), MasterBus 300E (MB300E), IEEE 802.3 (10Mbps Ethernet)
• Switch Modes: Position 1 (MB300 Standard), Position 3 (MB300E Extended)
• Power Supply: 24V DC (18-32V DC) | Current Consumption: 24V 0.25A, 5V 0.25A | Power Dissipation: 8W
• Protection: Built-in diagnostics, fault detection, ESD protection, overvoltage protection
• Operating Temperature: -40°C to +85°C | Storage Temperature: -40°C to +85°C
• Relative Humidity: 5%–95% (Non-Condensing) | Protection Class: IP20
• MTBF: >150,000 Hours | Dimensions: 234mm(L) × 108mm(W) × 18mm(H)
• Mounting: Rack-Mount (Advant Controller Chassis) | Weight: 0.2 kg | Shipping Weight: 2-3 kg
• Features: Hot-Swap Support, Plug-and-Play Integration, Redundant Configuration Capable
2. Core Features
• Dual Protocol Support: Switch-selectable MB300/MB300E for backward compatibility and extended functionality
• High-Speed Ethernet: IEEE 802.3 10Mbps for fast data exchange between DCS and field devices
• Built-in Diagnostics: Real-time fault detection and status monitoring for proactive maintenance
• Hot-Swap Capability: Replace module without system shutdown, minimizing downtime
• Plug-and-Play Integration: Easy installation into Advant Controller chassis with no additional configuration
• Redundant Configuration: Supports redundant communication setup for critical applications
• Industrial Durability: Wide temperature range (-40°C to +85°C) and robust design for harsh environments
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Process Control: Chemical plants, refineries, and pulp & paper mills with Advant Master DCS
• Power Generation: Fossil fuel, nuclear, and renewable energy power plants for data acquisition and control
• Oil & Gas: Offshore platforms, pipeline monitoring, and LNG facilities
• Manufacturing: Automotive, electronics, and food & beverage production lines with distributed control
• Water & Wastewater: Treatment plants for SCADA integration and remote monitoring
4. Installation & Maintenance
Installation: Insert into Advant Controller rack (ensure proper seating); Connect 24V DC power; Set switch mode (MB300/MB300E); Connect Ethernet cable to network; Verify communication via diagnostics tools; Configure network settings (IP address, subnet mask).
Maintenance: Daily - Check module status LEDs (Power, Link, Activity); Weekly - Inspect cable connections and rack ventilation; Monthly - Run diagnostic tests and update firmware if needed; Annual - Clean module and rack, check power supply stability.
Safety Notes: Power off before installation/removal; Use ESD protection (wrist strap, antistatic mat); Follow ABB grounding guidelines; Avoid exposure to moisture and extreme temperatures.
Technical Document | CS513 3BSE000435R1 | ABB IEEE 802.3 LAN Communication Module
