UFC718AE01 HIEE300936R0101 PROFIBUS DP‑V1 Communication Interface Module-KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB UFC718AE01 HIEE300936R0101 PROFIBUS DP‑V1 Communication Interface Module
Freelance/AC 800F/DCS 800xA Series - High‑Speed Fieldbus Interface for Deterministic Industrial Data Exchange
1. Product Overview
The ABB UFC718AE01 HIEE300936R0101 is a high‑performance PROFIBUS DP‑V1 communication interface module designed for ABB Freelance, AC 800F, and DCS 800xA industrial automation systems, acting as a critical data exchange bridge between controllers, remote I/O, and field devices (sensors, actuators, motor drives) in distributed control environments. Compliant with EN 50170, it supports master/slave configuration, automatic baud rate detection (9.6 kbit/s–12 Mbit/s), and DP‑V1 for acyclic data transfer, enabling seamless integration with third‑party PROFIBUS systems via standard GSD files. Equipped with RS‑485 electrical isolation (1500V AC) and redundant power input, the module ensures reliable operation in harsh industrial settings where real‑time communication and system availability are paramount.
Key Specifications
• Model: UFC718AE01 | Ordering Code: HIEE300936R0101 | Brand: ABB | Series: UFC700, Freelance/AC 800F/DCS 800xA
• Type: PROFIBUS DP‑V1 Communication Interface Module (Fieldbus Gateway)
• Input Voltage: 24V DC (18–32V DC) | Power Consumption: 8W (Typical)
• Communication Protocol: PROFIBUS DP (EN 50170), DP‑V1 (Acyclic Data), ABB System Bus
• Data Rate: 9.6 kbit/s–12 Mbit/s (Auto/Manual) | Electrical Interface: RS‑485 (9‑Pin D‑Sub)
• Operation Modes: Configurable as PROFIBUS Master or Slave | Max Slaves (Master): Up to 126
• Isolation: 1500V AC (1min, Bus‑to‑Control Side) | ESD Protection: ±8kV (Contact), ±15kV (Air)
• Operating Temperature: -20°C to +60°C | Storage Temperature: -40°C to +85°C
• Relative Humidity: 5%–95% (Non‑Condensing) | Protection Class: IP20 (Front Panel)
• MTBF: >120,000 Hours | Dimensions: 130mm (W) × 100mm (D) × 42mm (H)
• Weight: 0.4 kg | Installation: DIN Rail Mounting (35mm)
• Protection Features: Redundant Power Input, Overcurrent, Undervoltage, Overtemperature, Short‑Circuit
2. Core Features
• DP‑V1 Compliance: Supports cyclic/acyclic data transfer for diagnostics and parameterization
• Master/Slave Flexibility: Configurable role to match system architecture
• Auto Baud Rate: 9.6 kbit/s–12 Mbit/s for plug‑and‑play integration
• GSD File Support: Standard GSD for third‑party PROFIBUS device integration
• Isolated RS‑485: 1500V AC isolation prevents ground loops and electrical noise
• Redundant Power: Dual 24V DC inputs for uninterrupted operation
• LED Diagnostics: Power (Green), Run (Green), Fault (Red), Bus Activity (Yellow) for quick status checks
• DIN Rail Mount: Tool‑less installation on 35mm rail for easy replacement
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Generation: DCS Fieldbus Integration for Boiler/Turbine Auxiliary Systems
• Oil & Gas: Pipeline Pressure Control, Compressor Monitoring, Refinery Distributed I/O Networks
• Chemical Industry: Reactor Process Control, Batch Data Synchronization, Valve Actuator Networks
• Manufacturing: Production Line Automation, Robot Control, Motor Drive Fieldbus Connectivity
• Water & Wastewater: Pump Station Control, Flow Monitoring, Treatment Plant I/O Integration
• Third‑Party System Integration: Connect legacy PROFIBUS devices to ABB Freelance/AC 800F/DCS 800xA
4. Installation & Maintenance
Installation: Mount on 35mm DIN rail; Connect 24V DC redundant power; Wire RS‑485 (9‑Pin D‑Sub) to PROFIBUS network; Configure master/slave mode and baud rate via ABB Control Builder; Load GSD files for third‑party devices; Test cyclic/acyclic data transfer and redundancy switchover.
Maintenance: Daily – Check status LEDs (Power: Green, Run: Green, Fault: Red, Activity: Yellow); Weekly – Inspect terminal tightness and power stability; Annual – Clean dust, verify isolation, update firmware via ABB Service Tool.
Safety Notes: De‑energize before wiring; Use ESD protection during handling; Follow ABB PROFIBUS installation guidelines for proper termination/grounding.
