UBC717AE01 HIEE300927R0101 Universal Bus Communication Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB UBC717AE01 HIEE300927R0101 Universal Bus Communication Module
AC800M/DCS 800xA Series - High-Speed Data Exchange Module for Multi-Controller Industrial Automation Networks
1. Product Overview
The ABB UBC717AE01 HIEE300927R0101 is a universal bus communication module designed for ABB AC800M and DCS 800xA industrial automation systems, serving as a high-speed data exchange bridge between multiple controllers, remote I/O, and field devices in large-scale distributed control systems (DCS). It supports deterministic real-time communication with ultra-low latency (≤1ms) and integrates redundant communication channels, multi-protocol compatibility (Profibus DP, Modbus TCP/IP, Ethernet/IP), and comprehensive fault diagnosis functions. The module ensures seamless coordination between control units in power generation, oil & gas, chemical, and manufacturing industries where system integration, data synchronization, and operational reliability are critical.
Key Specifications
• Model: UBC717AE01 | Ordering Code: HIEE300927R0101 | Brand: ABB | Series: AC800M/DCS 800xA
• Type: Universal Bus Communication Module for Multi-Controller Data Exchange
• Input Voltage: 24V DC (18-32V DC) | Power Consumption: 10W (Typical)
• Communication Protocols: Profibus DP (12Mbps Max), Modbus TCP/IP, Ethernet/IP, ABB AC800M Bus
• Communication Interfaces: 2x Ethernet (10/100/1000 Mbps), 1x Profibus DP, 1x RS-485 (Modbus RTU)
• Data Transfer Rate: 12Mbps (Profibus DP), 1Gbps (Ethernet) | Latency: ≤1ms (Deterministic Communication)
• I/O Expansion: Supports up to 32 Remote I/O Modules | Isolation: 1500V AC (1min, Power-to-Signal)
• Operating Temperature: -20°C to +60°C | Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% - 95% (Non-Condensing) | Protection Class: IP20 (Front Panel)
• MTBF: >120,000 Hours | Dimensions: 130mm (W) × 100mm (D) × 42mm (H)
• Weight: 0.5 kg | Installation: DIN Rail Mounting (35mm)
• Protection Features: Redundant Power Input, Overcurrent, Undervoltage, Overtemperature, ESD Protection
2. Core Features
• High-Speed Deterministic Communication: ≤1ms latency for real-time data exchange between controllers
• Multi-Protocol Compatibility: Profibus DP, Modbus TCP/IP, Ethernet/IP for seamless system integration
• Redundant Design: Dual power input and communication channels for maximum system availability
• Remote I/O Expansion: Supports up to 32 remote I/O modules for flexible system configuration
• Fault Diagnosis: Built-in self-diagnostic functions and LED indicators for quick troubleshooting
• DIN Rail Mounting: Easy installation and replacement in control cabinets
• Wide Operating Voltage: 18-32V DC input for compatibility with industrial power supplies
• ESD Protection: ±8kV (Contact), ±15kV (Air) for reliable operation in harsh industrial environments
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Generation: DCS Data Exchange for Boiler, Turbine, and BOP Systems in Thermal/Hydropower Plants
• Oil & Gas: Pipeline Control, Compressor Monitoring, and Refinery Multi-Controller Coordination
• Chemical Industry: Reactor Temperature/Pressure Regulation and Batch Process Data Synchronization
• Manufacturing: Production Line Automation, Robot Control, and Quality Inspection System Integration
• Water & Wastewater: Pump Station Control, Flow Monitoring, and Treatment Process Data Exchange
• Safety Instrumented Systems (SIS): High-Speed Communication Bridge Between SIS and BPCS
4. Installation & Maintenance
Installation: Mount on 35mm DIN rail; Connect 24V DC power (redundant input recommended); Wire communication interfaces (Ethernet/Profibus/Modbus); Connect to AC800M controllers; Configure protocols and data exchange parameters via ABB Control Builder; Test communication latency and redundancy switchover.
Maintenance: Daily - Check status LEDs (Power: Green, Run: Green, Fault: Red); Weekly - Inspect terminal connections and power stability; Annual - Clean dust, verify isolation performance, and update firmware via ABB Service Tool.
Safety Notes: De-energize before wiring; Use ESD protection during handling; Follow ABB DCS safety guidelines for high-voltage isolation.
Technical Document | UBC717AE01 HIEE300927R0101 | ABB AC800M Universal Bus Communication Module
