HIMA F6706 2‑Channel Safety Analog Output Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
HIMA F6706 2‑Channel Safety Analog Output Module
SIL3 Certified Analog Output Module for Safety‑Critical Process Control & Actuator Regulation
1. Product Overview
The HIMA F6706 is a 2‑channel safety analog output module designed for HIMA HIMatrix safety instrumented systems (SIS). Certified to TÜV AK6/SIL3 (compliant with IEC 61508 and IEC 61511), it converts digital control signals to precise 4‑20 mA or 0‑10 V analog outputs for controlling valves, actuators, and other process equipment in safety‑critical applications. The module features dual‑channel isolation, short‑circuit protection, and real‑time self‑diagnostics, ensuring reliable operation in harsh industrial environments like oil & gas, chemical, and power generation.
2. Key Technical Specifications
• Product Type: 2‑Channel Safety Analog Output Module (Safety‑Related)
• Brand & Model: HIMA F6706 (HIMatrix Series)
• Output Channels: 2 Independent Safety Analog Output Channels
• Output Signals: 4‑20 mA DC (Current), 0‑10 V DC (Voltage) (Selectable per Channel)
• Resolution: 12‑Bit (4096 Steps)
• Accuracy: ±0.1% of Full Scale (25°C, Typical)
• Load Capacity: 500 Ω (4‑20 mA), 10 kΩ (0‑10 V)
• Safety Isolation: Class AK 1‑6 (TÜV Compliant)
• Short‑Circuit Protection: Short‑Circuit Proof (Max. 1.5 A Short Circuit Current)
• Response Time: Typical 250 ms (Including Filter & Conversion)
• Power Supply: 5 V DC (150 mA), 24 V DC (200 mA)
• Operating Temperature: -20°C to +60°C (-4°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity: 5%‑95% RH (Non‑Condensing)
• Protection Class: IP20 (Indoor Cabinet Mount)
• Space Requirement: 4 TE (DIN Rail Mount)
• Weight: 0.18 kg (0.40 lbs)
• Certification: TÜV AK6/SIL3, IEC 61508, IEC 61511
3. Core Features
• SIL3 Safety Compliance: TÜV AK6/SIL3 certified, meeting the highest safety standards for critical applications.
• Dual‑Channel Isolation: Independent isolation between channels and power supply to prevent cross‑interference.
• High Precision: 12‑bit resolution and ±0.1% accuracy for precise process control.
• Short‑Circuit Protection: Built‑in short‑circuit proof design to protect the module and connected loads.
• Real‑Time Diagnostics: Self‑diagnostic functions for fault detection, alarm, and predictive maintenance.
• Hot‑Swappable: Replaceable without system shutdown (in redundant configurations) for reduced downtime.
• Flexible Configuration: Selectable output type (current/voltage) per channel via HIMatrix Engineering Studio.
4. Typical Applications
• Oil & Gas: Valve position control, flow control, and wellhead pressure regulation in ESD systems.
• Chemical Industry: Reactor temperature control, pressure regulation, and hazardous material dosing.
• Power Generation: Boiler feedwater control, turbine speed regulation, and flue gas emission control.
• Pharmaceutical: Production line process parameter control and cleanroom environment regulation.
• Water & Wastewater: Pump speed control, chemical dosing system regulation, and flow monitoring.
5. Installation & Maintenance
• Mounting: 4 TE DIN Rail Mount in HIMatrix I/O Racks (Max. 10 Modules per Rack).
• Wiring: Use shielded twisted‑pair cables for output signals; Ensure proper load matching.
• Configuration: Use HIMA HIMatrix Engineering Studio to Set Output Type, Range, and Filter Parameters.
• Calibration: Factory‑calibrated; Self‑calibration via Built‑in Diagnostic Functions.
• Maintenance: Hot‑Swappable (Redundant Configurations); Diagnostic Logs for Fault Tracing.
• Troubleshooting: LED Status Indicators and HIMatrix Diagnostic Reports for Quick Fault Identification.
Technical Document | HIMA F6706 | 2‑Channel Safety Analog Output Module | SIL3 Safety Certification
