ABB PP846A 3BSE042238R2 Panel 800 High - Performance HMI Operator Panel

Product Description

The ABB PP846A 3BSE042238R2 is a high - performance HMI operator panel belonging to the Panel 800 series, specifically designed for seamless human - machine interaction in industrial automation and process control systems. It features a 10.4 - inch TFT color touchscreen with 800×640 resolution and 10 customizable function keys, enabling operators to monitor processes, adjust parameters, and respond to alarms efficiently. With a 24VDC ±20% power supply, 2GB RAM, and 16GB Flash memory, it delivers smooth operation and ample data storage. The front panel boasts an IP65 protection rating, while the device operates reliably in a -10°C to +60°C temperature range, making it suitable for harsh factory and process environments. It integrates with ABB AC 800M controllers and supports multiple industrial communication protocols (Ethernet, RS - 485, Modbus RTU/TCP, ABB CS311), ensuring seamless data exchange with control systems and field devices for enhanced operational efficiency and safety.

Key Functions

The PP846A 3BSE042238R2 offers comprehensive HMI capabilities for industrial control: 10.4 - inch high - resolution TFT touchscreen (800×640) for clear process visualization, parameter display, and alarm notification; 10 programmable function keys for one - click access to critical operations and system functions; 2GB RAM and 16GB Flash memory for smooth running of complex HMI applications and data logging; 24VDC ±20% wide - range power input for stable operation in industrial power environments; IP65 - rated front panel for dust and water resistance in harsh industrial settings; Multi - protocol communication support (Ethernet, RS - 485, Modbus RTU/TCP, ABB CS311) for seamless integration with ABB AC 800M and third - party control systems; Real - time alarm management with visual and audible alerts for prompt operator response to abnormal conditions; Data logging and trend analysis functions for process optimization and predictive maintenance; User - level access control and password protection to ensure operational security and prevent unauthorized changes; Compact dimensions (254×152×50.8mm) and panel - mount design for easy installation in control cabinets.

Application Scenarios

The PP846A 3BSE042238R2 excels in diverse industrial automation and process control applications: Process control in chemical, petrochemical, and pharmaceutical plants, enabling operators to monitor and adjust production parameters in real time; Power generation facilities, providing HMI interfaces for turbine, boiler, and generator control systems; Manufacturing lines in automotive, electronics, and food processing industries, facilitating equipment monitoring, production scheduling, and quality control; Water and wastewater treatment plants, supporting process monitoring, pump control, and chemical dosing adjustment; Oil and gas upstream/downstream operations, offering reliable HMI for wellhead control, pipeline monitoring, and refinery process management; Building automation systems, enabling centralized control and monitoring of HVAC, lighting, and security systems; Retrofit projects for upgrading legacy HMI panels to modern, high - performance interfaces with enhanced connectivity and functionality; Remote monitoring stations in harsh environments, leveraging IP65 front panel protection and wide temperature tolerance for continuous operation.

Technical Specifications

• Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
• Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
• Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
• Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
• Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
