ABB ACS6000 S-073H 3BHB009884R0002 7 MV High-Impulse Phase Module

Product Description

The ABB S-073H 3BHB009884R0002 is a high-impulse Phase Module tailored for the ACS6000 medium - voltage (MV) drive series, leveraging Modular Multilevel Converter (MMC) technology and IGCT semiconductors to deliver 7 MV high - impulse operation. It integrates precision gate drivers, real - time thermal monitoring, and redundant cooling interfaces (forced air/liquid) to thrive in harsh industrial settings. Boasting a modular hot - swap design, it allows for maintenance without shutting down the entire drive. It complies with IEC 61800 - 5 - 1 safety standards, operates within an ambient temperature range of - 10°C to + 40°C, and has an IP20 front - panel protection rating, guaranteeing long - term stability in mission - critical motor control applications.

Key Functions

The S-073H 3BHB009884R0002 provides core 7 MV high - impulse drive phase control functions: Precise phase voltage and current regulation via MMC technology, ensuring smooth motor speed and torque control while meeting IEEE 519 grid harmonic compliance; 7 MV high - impulse operation to tackle dynamic heavy - industry loads; Hot - swap capability enabling module replacement without system downtime; Real - time thermal, overcurrent, and overvoltage protection to protect IGCT semiconductors; Seamless integration with ACS6000 controllers for centralized diagnostics and monitoring; Redundant cooling compatibility (forced air/liquid) for flexible deployment; Comprehensive fault detection with alarm signaling and time - stamped event logging for predictive maintenance; Modular scalability to support the expansion of drive system capacity.

Application Scenarios

The S-073H 3BHB009884R0002 excels in 7 MV high - impulse motor control across mission - critical industrial sectors: In the metallurgy industry, it controls rolling mill main drives, ensuring precise speed synchronization and product quality; For power generation, it regulates boiler feed pumps, induced draft fans, and turbine auxiliary drives; In mining, it powers large conveyor belt and hoist motor systems, enhancing energy efficiency and operational uptime; For petrochemical refining, it drives high - power compressors and pumps in distillation and cracking units; In the pulp & paper industry, it controls paper machine main drives and pulp mill process pumps; It also supports marine ship propulsion and thruster motor drives that demand dynamic load handling.

Technical Specifications

• Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
• Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
• Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
• Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
• Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
