ABB S-093M 3BHB009885R0013 Phase Module for 9 MV ACS6000 Medium Voltage Drives

Product Description

The ABB S-093M 3BHB009885R0013 is a high-power Phase Module engineered for the ACS6000 9 MV medium voltage (MV) drive series, built on Modular Multilevel Converter (MMC) technology with IGCT semiconductors for efficient, low-harmonic power conversion. It integrates precision gate drivers, real-time thermal monitoring, and redundant cooling interfaces (forced air/liquid) to adapt to heavy-industry environments. The module features a modular hot-swap design for maintenance without full drive shutdown, complies with IEC 61800-5-1 safety standards, operates at -10°C to +40°C ambient temperatures, and offers IP20 front-panel protection, ensuring long-term stability in mission-critical motor control applications.

Key Functions

The S-093M 3BHB009885R0013 delivers core 9 MV drive phase control capabilities: High-precision phase voltage/current regulation via MMC technology for smooth motor speed/torque control and IEEE 519 grid harmonic compliance; 9 MV standard impulse operation to handle dynamic heavy-industry loads; Hot-swap functionality enabling module replacement without system downtime; Real-time thermal/overcurrent/overvoltage protection to safeguard IGCT semiconductors; Seamless integration with ACS6000 controllers for centralized diagnostics and monitoring; Redundant cooling compatibility (forced air/liquid) for flexible deployment; Comprehensive fault detection with alarm signaling and time-stamped event logging for predictive maintenance; Modular scalability to support drive system capacity expansion.

Application Scenarios

The S-093M 3BHB009885R0013 excels in 9 MV motor control for mission-critical industrial sectors: Metallurgy for rolling mill main drives, ensuring precise speed synchronization and product quality; Power generation for boiler feed pumps, induced draft fans, and turbine auxiliary drives; Mining for large conveyor belt and hoist motor systems, optimizing energy efficiency and uptime; Petrochemical refining for high-power compressor and pump drives in distillation/cracking units; Pulp & paper for paper machine main drives and pulp mill process pumps; Marine for ship propulsion and thruster motor control, supporting dynamic load changes; General heavy industry for high-power motor control requiring low harmonics and maximum reliability.

Technical Specifications
