ABB DSQC633C 3HAC043904-001 Measurement Board Origina New In Stock
- Part number：ABB DSQC633C 3HAC043904-001
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: ABB DSQC633C 3HAC043904-001 – IRC5 Robot SMB Serial Measurement Board
ABB DSQC633C (3HAC043904-001) SMB Unit Serial Measurement Board for IRC5 Industrial Robot Controller
DSQC633C 3HAC043904-001 is the SMB (Serial Measurement Board) measurement interface card of ABB IRC5 robot control cabinet, used to read serial position feedback signals from robot motor absolute encoders. It is the core signal acquisition board for robot axis position detection, supporting multi-axis encoder signal reception, data decoding and real-time position upload to the main computer unit. DSQC633C is the hardware model, 3HAC043904-001 is the complete assembly spare part number, compatible with single cabinet IRC5 Compact, IRC5 M2004 and multi-cabinet IRC5 Dual controller systems, widely matched with IRB series 6-axis industrial robots, handling robots and palletizing robots.
Core Technical Specifications
- Model: DSQC633C | Full Spare PN: 3HAC043904-001 | Brand: ABB Robotics
- Device Type: SMB Serial Measurement Encoder Feedback Board
- Supported Axis: Up to 6 robot axes serial encoder signal input, expandable with external SMB modules
- Encoder Interface: ABB proprietary SMB serial differential bus, compatible with multi-turn absolute encoders
- Backplane Communication: CompactPCI internal bus, high-speed real-time position data transmission
- Front Connectors: Multiple SMB multi-core cable sockets for robot motor encoder harness connection
- Power Supply: 5VDC & 24VDC supplied by IRC5 cabinet backplane power module
- Status Indicators: Power OK, Bus Link, Channel Fault LED indicators for quick fault diagnosis
- Cabinet Compatibility: IRC5 Compact, IRC5 Single, IRC5 Dual robot controller rack slot installation
- PCB Protection: Conformal coating, anti-dust and anti-moisture for workshop production environment
- Operating Temperature: 0°C ~ +55°C | Storage Temperature: -40°C ~ +85°C
- Certifications: CE, UL industrial automation EMC anti-interference standard
Main Functional Features
- Real-time collection of absolute encoder position data of each robot joint, no zero return required after power-off, retain mechanical origin position permanently
- Differential serial signal transmission design, strong anti-interference, adapt to high-frequency electromagnetic environment of welding and cutting workshops
- Independent channel fault detection, real-time alarm for encoder cable disconnection, short circuit, signal loss and communication timeout
- High-speed data synchronization with main computer board, ensure high-precision robot motion interpolation and positioning repeatability
- Support robot jogging, automatic trajectory operation, soft limit and mechanical limit position monitoring judgment
- Standard CompactPCI plug-in card, power-off hot swappable, convenient on-site spare replacement without cabinet disassembly
- Fully compatible with RobotStudio offline programming software, upload axis position data for calibration, jogging and fault log analysis
- Built-in signal filtering and surge suppression circuit, effectively eliminate interference caused by servo drive and welding equipment
Application Industries
- Automotive Manufacturing: Welding, handling, painting ABB IRB series robot IRC5 control cabinet
- 3C Electronics Assembly: Small high-speed handling, assembly robot encoder signal acquisition unit
- Food & Packaging: Palletizing, packaging robot position measurement feedback board
- Metal Processing: Cutting, polishing industrial robot IRC5 controller spare part
- Robot Maintenance & Retrofit: Replacement SMB board for aging IRC5 robot control systems
Product Picture
