ABB DSQC604 (3HAC12928-1) Digital I/O Module for IRC5 Robot Controller
Product Description
The ABB DSQC604 (Ordering Part Number: 3HAC12928-1) is a high-density, rugged digital input/output (I/O) module engineered exclusively for the ABB IRC5 robot controller—core to industrial robotic automation systems. This rack-mount module provides a flexible, expandable I/O interface to connect the robot controller with external devices (sensors, actuators, safety circuits, PLCs, HMIs) in manufacturing, automotive, packaging, and material handling applications. It features 16 digital inputs and 16 digital outputs, built-in overvoltage/overcurrent protection, hot-swappable capability, and seamless integration with ABB RobotStudio software for configuration, monitoring, and troubleshooting—ensuring reliable, real-time signal exchange in harsh industrial environments.
Key Functions
The DSQC604 digital I/O module delivers robust, flexible I/O expansion for IRC5 robot controllers with these core capabilities: 16 isolated digital inputs (24 VDC, sink/source configurable) for sensor feedback, safety interlocks, and position signals; 16 protected digital outputs (24 VDC, 2 A per channel, short-circuit/overload protection) for actuating grippers, valves, conveyors, and other peripheral equipment; seamless integration with the IRC5 controller’s DeviceNet/Profibus DP fieldbus interfaces for PLC/HMI communication; hot-swappable design for module replacement without robot controller shutdown; built-in diagnostics (overload, short-circuit, open-wire detection) with LED status indicators for quick fault isolation; support for ABB RobotStudio software for I/O mapping, signal monitoring, and logic programming.
Application Scenarios
The ABB DSQC604 is deployed in industrial robotic automation systems requiring reliable, high-density I/O connectivity. In automotive manufacturing, it connects IRC5 controllers with welding guns, grippers, conveyor systems, and safety fences for body-in-white assembly, paint shop automation, and powertrain production. For packaging and material handling applications, it integrates with sensors, sorters, and palletizers to enable automated picking, packing, and shipping operations. In general manufacturing, it links robots with CNC machines, inspection stations, and part feeders for flexible production lines. The module is also ideal for harsh industrial environments (high vibration, temperature fluctuations) where robust I/O protection and reliable signal exchange are critical.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital I/O Module for ABB IRC5 Robot Controller |
| Manufacturer | ABB Robotics |
| Model/Part Numbers | DSQC604 / 3HAC12928-1 |
| Digital Inputs | 16 Channels, 24 VDC (18–30 VDC Range); Isolated; Sink/Source Configurable; Response Time < 1 ms |
| Digital Outputs | 16 Channels, 24 VDC; 2 A per Channel (Max); Short-Circuit & Overload Protection; Response Time < 1 ms |
| Power Requirements | 24 VDC (from IRC5 Controller Chassis); Typical Power Consumption: 5 W |
| Communication Interface | Backplane Connection to IRC5 Controller; Supports DeviceNet/Profibus DP for PLC Integration |
| Operating Environment | Temperature: 0°C to 45°C (32°F to 113°F); Humidity: 5–95% RH (Non-Condensing); Vibration Compliant with IEC 60068-2-6 |
| Mechanical Design | Rack-Mount for IRC5 Controller Chassis; Hot-Swappable; Front-Panel Status LEDs; IP20 Protection Rating |
| Certifications | CE, UL, CSA; Compliant with EN 61131-2, IEC 61010-1 Industrial Standards |
