Brief Product Description

3500/60, part number 136711‑01, is a six‑channel temperature monitoring module for the Bently Nevada 3500 machinery protection system, complying with API 670 standards. It accepts both RTD and thermocouple input signals for bearing metal, stator and process temperature measurement. Without recorder output ports, this rack‑mount unit delivers signal conditioning, temperature calculation and user‑configurable alarm threshold comparison. It supports TMR triple‑modular redundant deployment for high‑availability machinery protection. Equipped with on‑board self‑diagnostics and front‑panel LED status indicators, it ensures stable 24‑7 operation inside industrial TSI cabinets and acts as essential spare hardware for legacy system maintenance and retrofit projects.

Core Product Functions

• Six independent input channels supporting mixed RTD and thermocouple sensor signals for multi‑point temperature acquisition
• Precise temperature and differential‑temperature calculation for bearing, stator and process thermal monitoring
• User‑programmable high‑alarm and danger‑alarm setpoints to trigger system alarm and shutdown interlock logic
• Signal conditioning and filtering to suppress field electromagnetic interference in plant cabinet environments
• Supports triple‑modular redundant (TMR) configuration with voting logic for safety‑critical machinery protection
• Comprehensive channel self‑diagnosis for open‑circuit, short‑circuit and internal hardware fault detection
• Front‑panel LED indicators display module health status, channel condition and active alarm events
• High‑speed data communication with 3500 rack backplane, uploading temperature data to System 1 predictive maintenance software

• Channel‑to‑channel isolation option minimizes ground‑loop disturbance for reliable field measurement

Application Scenarios

• Bently Nevada 3500 TSI machinery protection racks for steam turbine, gas turbine and generator sets in power plants
• Oil & gas on‑site and offshore platform centrifugal compressor and turbo‑machinery monitoring cabinets
• Petrochemical plant rotating‑equipment bearing and winding temperature protection systems
• Metallurgical heavy‑duty turbomachinery, large pump and fan thermal monitoring installations
• Process industry safety interlock systems requiring API‑670 compliant temperature protection

• Spare replacement temperature monitor module for maintenance, expansion and upgrade of existing 3500 series systems

FAQ (Frequently Asked Questions)

• Q: Module reports channel fault or temperature reading shows abnormal value?
  A: Inspect RTD / thermocouple sensor failure, field cable open‑circuit or short‑circuit, terminal loose contact, backplane connection or module hardware aging.
• Q: Alarm triggers falsely while actual equipment temperature remains normal?
  A: Check ground‑loop interference, incorrect sensor type configuration in rack software, wiring mistake or degraded cable insulation.
• Q: Can 3500/60 136711‑01 be hot‑swapped while the 3500 rack stays powered?
  A: Hot‑swap is not permitted. Follow lock‑out tag‑out procedures and power off the rack before replacement to avoid unintended machinery trip.
• Q: Can this module be substituted by 3500/61?
  A: 3500/61 adds recorder output channels. Functional match requires full configuration review; direct drop‑in replacement is not always feasible.
• Q: Is Bently Nevada 3500/60 136711‑01 available for brand‑new TSI projects?
  A: This legacy monitoring module has reached end‑of‑life. Only surplus and fully‑tested refurbished units are supplied for existing‑site maintenance work.
