ABB 500PSM03/500PSM03A (1MRB150038R1) 100W Industrial Power Supply Module
High‑Efficiency Redundant Power for ABB AC500 PLC Automation Systems
1. Core Product Overview
The ABB 500PSM03/500PSM03A (order code: 1MRB150038R1) is a high‑efficiency 100W industrial power supply module designed for the ABB AC500 PLC series, serving as the core power unit for AC500 CPU, I/O modules and peripheral automation components in critical industrial processes requiring high availability. 500PSM03A is a supply chain variant of the 500PSM03 base model, with identical core performance and compatibility, optimized for global industrial power grids with dual input support for 85-264V AC and 110-300V DC, and delivering regulated 24V DC/4.2A output with ultra‑low ripple (<50mV). It supports seamless 1+1 redundant power configuration, enabling parallel connection of two modules for uninterrupted system operation during single module failure. Built with industrial‑grade ruggedness, it integrates multi‑level electrical protection, IEC‑compliant EMC/surge safeguards and thermal management, operating stably in -20°C to +70°C harsh environments with strong electromagnetic interference and extreme temperatures. Fully compatible with all AC500 series components, it achieves plug‑and‑play installation with FBP bus auto‑recognition, making it an essential component for building stable and fault‑tolerant AC500 automation systems.
• Core Role: AC500 PLC main power supply; 24V DC power distribution for CPU/I/O modules; redundant power support; critical process power backup; system power fault monitoring
• Model Info: 500PSM03 (base model); 500PSM03A (supply chain variant); 1MRB150038R1 (ABB official order code); AC500 100W redundant power module
• Key Specs: 85-264V AC/110-300V DC dual input; 24V DC/4.2A (100W) output;<50mV ripple; 1+1 redundant parallel; IP20 protection; -20°C~+70°C operating temp
• Reliability: Multi‑level electrical protection; 92% max efficiency; IEC 61000‑4 EMC compliance; redundant auto‑switchover; front‑panel status indication
2. Power Performance & Electrical Specs
The 500PSM03/500PSM03A 1MRB150038R1 features a dual‑input design supporting both 85-264V AC (50/60Hz) and 110-300V DC, adapting to global industrial power grids and DC power systems without voltage adjustment, and tolerating ±20% input voltage fluctuations to ensure stable power supply in sites with unstable mains power. It outputs regulated 24V DC with a rated current of 4.2A (100W power capacity), capable of powering a full AC500 system including 1 CPU module and up to 30 I/O modules, with ultra‑low output ripple (<50mV) and voltage accuracy (±1%) to protect sensitive PLC electronic components. The module has a high conversion efficiency of up to 92%, reducing power loss and heat generation. It supports 1+1 redundant power configuration—two 500PSM03/500PSM03A modules can be connected in parallel with built‑in ORing diodes to realize seamless power switchover (<5ms) in case of single module failure, ensuring uninterrupted operation of critical industrial processes.
• Dual Input: 85-264V AC (50/60Hz) + 110-300V DC; ±20% input voltage fluctuation tolerance; global power grid compatibility
• DC Output: 24V DC regulated; 4.2A rated current (100W); ±1% voltage accuracy;<50mV peak‑to‑peak ripple; 92% max conversion efficiency
• Redundancy: 1+1 redundant parallel connection; built‑in ORing diodes;<5ms seamless switchover; no additional redundancy module required
• Power Capacity: Drives 1 AC500 CPU + up to 30 I/O modules; 24V DC sensor excitation output; low power loss (<10W at full load)
3. Protection Features & Industrial Ruggedness
The 500PSM03/500PSM03A 1MRB150038R1 is built with a multi‑level integrated protection system to ensure the safety of the module and connected AC500 components. It includes overvoltage protection (28V DC output cutoff), overcurrent protection (auto‑current limiting), short‑circuit protection (auto‑shutdown with recovery) and thermal overload protection (temperature‑based power cut)—all protection functions are self‑recovering after fault elimination, no manual reset needed. The module complies with IEC 61000‑4 EMC/surge protection standards, with built‑in surge suppressors and EMC filters to resist electromagnetic interference from industrial equipment (frequency converters, high‑voltage motors) and power grid surges. Designed for industrial environments, it has anti‑vibration (5-50Hz, IEC 60068) and anti‑shock performance, and an IP20 front panel protection rating to prevent dust and accidental contact, operating stably in -20°C to +70°C extreme temperature ranges.
• Electrical Protection: 28V DC overvoltage cutoff; overcurrent current limiting; short‑circuit auto‑recovery; thermal overload protection
• EMC/Surge Protection: IEC 61000‑4‑2/3/5 compliant; anti‑static; surge resistance; EMC filter; power grid interference suppression
• Environmental Ruggedness: -20°C~+70°C operating temperature; 5-50Hz anti‑vibration (IEC 60068); anti‑shock; IP20 front dust protection
• Long‑Term Reliability: Low power loss; low heat generation; industrial‑grade components; 100,000+ hours MTBF; no battery required
4. AC500 Integration & Installation
The 500PSM03/500PSM03A 1MRB150038R1 achieves plug‑and‑play integration with all ABB AC500 series PLC components, including CPUs (500CPU03), digital/analog I/O modules (500BIM01/500AIM02), temperature modules (500MTM02/500ITM02) and communication modules (500CSP04)—no additional configuration for basic power supply, and the power bus is automatically connected when mounted on the AC500 DIN rail rack. It features standard 35mm DIN rail mounting with a compact form factor (120×100×65mm), fitting into standard industrial control cabinets and supporting side‑by‑side installation for redundant power configuration. The module uses spring‑type terminal blocks for fast, tool‑free and reliable on‑site wiring, with clearly marked input/output terminals to avoid wiring errors, and the front panel is equipped with intuitive LED indicators (AC/DC Input/DC Output/Power/Fault) for real‑time visual diagnosis of power supply status. A dedicated fault signal output port transmits power fault information to the AC500 CPU for remote monitoring and alarm.
• Compatibility: Plug‑and‑play with all AC500 series modules; automatic power bus connection; redundant power parallel connection support
• Mounting: 35mm standard DIN rail; 120×100×65mm compact size; side‑by‑side installation for redundancy; cabinet space‑saving design
• Wiring: Spring‑type terminal blocks; tool‑free fast wiring; clearly marked I/O terminals; anti‑wiring error design
• Status & Diagnosis: Front‑panel multi‑LED indicators; fault signal output port; remote status monitoring via AC500 CPU
5. Variant Note & Industrial Compliance
Variant Status: 500PSM03A is a supply chain variant of the 500PSM03 base model, with identical core performance, specs and AC500 compatibility—only minor batch/component variations for supply chain flexibility, fully interchangeable with 500PSM03 for spares and system upgrade.
Key Industrial Sectors: Chemical/petrochemical process control; thermal/hydro/wind/solar power generation; steel/metallurgy automation; water/wastewater treatment; building automation; mining machinery; automotive/packaging manufacturing; all AC500 PLC‑based automation systems.
Certifications & Compliance: IEC 61131‑2 (industrial control equipment); IEC 61010‑1 (electrical safety); IEC 61000‑4 (EMC/surge/anti‑static); IEC 60068 (vibration/shock); CE/UL/RoHS certified; IP20 front protection.
Spare Part & Warranty: ABB genuine original module; factory pre‑tested for power performance; 18‑month standard warranty; 100,000+ hours MTBF; fully compatible with all AC500 system firmware versions; technical support for redundant power system configuration.
