WOODWARD 9907-167 Digital Turbine Governor Controller Original New In Stock
- Part number：WOODWARD 9907-167
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: 9907-167 – WOODWARD 505E Digital Turbine Governor Controller
High Precision Digital Speed Governor for Single Extraction Steam Turbine & Turbo-Generator
9907-167 belongs to Woodward classic 505E series digital governor, original USA manufactured, dedicated to steam turbine speed, load and extraction pressure closed-loop control, adopts high-performance PID algorithm, widely used for power plant turbine, waste heat generator set, petrochemical turbo expander unit; original production phased out, mainly supplied as maintenance spare parts for legacy turbine control system。
Core Technical Parameters
- PN:9907-167 | Brand:WOODWARD (USA)
- Power Supply:18~32VDC standard 24VDC; optional 88~264VAC wide range AC input
- Control Precision:Speed control accuracy ±0.25%, overspeed trip precision ±0.05%FS
- Speed Detect Range:0~3000RPM, MPU pickup input 100Hz~32kHz
- I/O Configuration:2 analog actuator outputs,8 relay alarm outputs,6 programmable current output channels
- Communication:RS232+RS485 Modbus RTU, optional Ethernet expansion, connect DCS/PLC upper monitoring
- Dimension:356×279×102mm(14×11×4inch), Net Weight≈4.5kg, NEMA4 enclosure rating
- Ambient Spec:-40℃~+85℃ operating temp, IP67 dustproof & splash-proof, SIL2 safety certification
- Product Status:Discontinued original manufacturing, surplus new/refurbished available for replacement
Main Functional Features
- 30-key built-in keypad + LCD display, local parameter setting, real-time operating data view & fault code inquiry
- Multi-mode control: speed governing, load limiting, extraction/admission pressure cascade control for single extraction turbine
- Full protection:overspeed trip,MPU speed sensor fault,overload,undervoltage,overheat interlock protection
- Support redundant hot standby configuration, seamless master-slave switchover during controller failure
- Built-in fault diagnosis log storage, convenient field troubleshooting and maintenance
Application Fields
- Thermal power plant small & medium steam turbine generator unit control
- Chemical plant waste heat recovery turbine, petrochemical turbo expander speed regulation
- Cogeneration heating & power co-production turbine system retrofit & spare replacement
- Marine steam turbine auxiliary control, legacy Woodward 505 series system maintenance upgrade
Product Picture
