Woodward 8200-1302 Digital Input/Output Module

Product Description

The Woodward 8200-1302 is a high-reliability combined digital input/output (DIO) module designed for integration with Woodward's 8200 series control systems, engineered specifically for critical power generation, marine, and industrial turbine/compressor control applications requiring compact, multi-functional signal I/O capabilities. Built with rugged industrial-grade components, galvanic isolation, and advanced protection circuitry, this module delivers consistent performance in harsh environmental conditions (extreme vibration, electrical noise, wide temperature ranges) typical of power plants, offshore platforms, and industrial processing facilities. Its compact, rack-mount form factor integrates seamlessly with Woodward 8200 series chassis, while hot-swappable functionality enables maintenance without disrupting critical prime mover control processes. The 8200-1302 combines digital input and output capabilities in a single module with built-in diagnostic features, making it an essential component for monitoring safety interlocks and driving control actuators in turbine, generator, and compressor control systems.

Key Functions

The primary function of the Woodward 8200-1302 module is to provide combined digital input and output capabilities for Woodward 8200 series control systems, enabling integrated signal acquisition and actuation for critical rotating equipment control applications. It features 16 digital input channels (24 V DC optically isolated) for acquiring safety interlock signals (overspeed detection, low lubrication pressure, valve position) and 16 digital output channels (24 V DC sink/source) for driving solenoid valves, relays, and alarm annunciators—all in a single compact module. Each input channel includes surge protection and configurable delay filtering to eliminate transient signal interference, while each output channel provides overcurrent and short-circuit protection to withstand harsh electrical environments. The module supports real-time diagnostic capabilities to detect input/output faults (open/short circuits, overcurrent conditions), module malfunctions, and power supply issues, with LED status indicators for quick visual fault identification and diagnostic data communicated to Woodward's control software for alarm reporting and proactive maintenance. Additionally, the 8200-1302 complies with marine and industrial safety standards, offers deterministic response times for safety-critical operations, and supports seamless integration with Woodward's ProTech and Governor control systems.

Application Scenarios

The Woodward 8200-1302 DIO module is primarily deployed in critical rotating equipment control systems across power generation, marine, and industrial sectors. In fossil fuel power plants (gas/steam turbines), it integrates input/output functionality for monitoring turbine safety interlocks (overspeed switches, vibration sensors) and driving control valve actuators, emergency shutdown relays, and alarm systems within Woodward 8200 turbine control systems. For marine applications (shipboard main propulsion engines, auxiliary power generators), it provides combined digital I/O for monitoring engine safety switches (fuel pressure, cooling system status) and driving fuel system solenoids, emergency stop relays, and navigation alarm systems—complying with marine classification society standards (ABS, Lloyd's Register, DNV). In industrial compressor applications (natural gas pipeline compression stations, petrochemical plant compressors), it monitors anti-surge valve position switches and lube oil system status (inputs) while driving anti-surge control valves and emergency shutdown actuators (outputs) for Woodward compressor control systems. The module is also used in emergency diesel generator control systems for critical power backup (data centers, hospitals), where it monitors generator status interlocks and drives transfer switch actuators, and in renewable energy applications (biomass, waste-to-energy plants) for integrating turbine safety I/O and control actuation in compact control enclosures.
