ABB NGC8206 Natural Gas Chromatograph

Portable/Field-Mounted GC for Natural Gas Composition & Heating Value Analysis

1. Product Overview

The ABB NGC8206 is a compact, portable/field-mounted natural gas chromatograph (GC) designed for on-site analysis of natural gas composition, heating value (Btu/CV), and key quality parameters (relative density, Wobbe index, GPM). It delivers fast, reliable analysis of components from N₂ (air) to C6+ (with optional H₂S up to 1200 ppm){insert\_element\_0\_}, adhering to GPA 2172, ISO 6976, and AGA 8 standards. Equipped with a 32-bit Windows CE controller, modular design, and low-power operation (<7W), it supports custody transfer, pipeline monitoring, and spot-check applications where continuous online systems are impractical{insert\_element\_1\_}. Its 5-minute analysis cycle, historical data storage (480 cycles), and multi-stream capability (up to 4 sample streams) make it ideal for wellheads, distribution stations, and industrial gas users, reducing reliance on lab analysis and optimizing operational efficiency.

ABB NGC8206 (1).jpg

2. Key Technical Specifications

• Brand & Model: ABB NGC8206 (Natural Gas Chromatograph)

• Type: Portable/Field-Mounted GC for Natural Gas Analysis

• Analyzed Components: Air (N₂, Ar, CO, O₂), C1, CO₂, C2, C3, iC4, nC4, neoC5, iC5, nC5, C6+ (back-flushed); Optional H₂S (up to 1200 ppm){insert\_element\_2\_}

• Analysis Cycle Time: 5 Minutes (Typical)

• Sample Streams: Up to 4 (Configurable Auto-Calibration/Sample Streams)

• Calculations: Btu/CV, Relative Density, Wobbe Index, GPM, Compressibility (Z){insert\_element\_3\_}

• Standards Compliance: GPA 2172-96, ISO 6976-95, AGA 8, GPA 2261-99

• Controller: 32-bit Windows CE, Real-Time Data Processing & Reporting{insert\_element\_4\_}

• Power Consumption: < 7 Watts (Continuous Operation){insert\_element\_5\_}

• Dimensions: 17.1 cm × 40.6 cm × 22.9 cm (6.75" × 16" × 9")

• Weight: Approx. 12.7 kg (28 lb)

• Operating Temperature: -20°C to +50°C (-4°F to +122°F)

• Power Supply: 12 VDC (Vehicle) / 120/240 VAC (Fixed)

• Data Storage: 480 Analysis Cycles (Default Historical Data)

• Communication: Modbus RTU/TCP, Ethernet, USB (Data Export/Configuration)

• Carrier Gas: 99.995% Pure Helium (Chromatographic Grade)

ABB NGC8206 (5).jpg

3. Core Features

• Compact Design: Fits in tight spaces (1.1 cubic feet), lighter than traditional online GCs{insert\_element\_6\_}.

• Fast Cycle Time: 5-minute analysis for real-time decision-making in custody transfer.

• Low Power Operation:<7W enables continuous standby for immediate on-site use{insert\_element\_7\_}.

• Modular Architecture: Easy-to-replace analytical modules and sample system conditioners.

• Multi-Stream Flexibility: Supports 4 streams with auto-calibration for reliable long-term operation.

• Comprehensive Diagnostics: Built-in fault detection for oven temperature, carrier gas pressure, and flow.

• Historical Data Logging: Stores 480 cycles for audit trails and transmitter verification.

• Optional H₂S Analysis: Detects up to 1200 ppm for sour gas applications{insert\_element\_8\_}.

ABB NGC8206 (4).jpg

4. Typical Applications

• Natural Gas Pipelines: Custody transfer metering and quality verification at compressor stations and city gates.

• Wellhead Monitoring: Spot analysis of produced gas to optimize extraction and processing.

• Distribution Networks: Quality control at utility connection points to ensure customer supply standards.

• Industrial Gas Users: Verify fuel gas quality for boilers, turbines, and process heaters.

• LNG Terminals: Monitor feed gas composition and energy content during liquefaction/re-gasification.

• Mobile Inspection: Vehicle-mounted deployment for pipeline network spot-checks and leak detection support.

ABB NGC8206 (3).jpg

5. Installation & Maintenance

Installation Steps

• Mounting: Secure to pole/pipeline or vehicle bracket; ensure vertical orientation for proper cooling.

• Sampling System: Connect to sample point with heated lines (if required) and liquid rejection probes.

• Carrier Gas: Connect 99.995% pure helium to regulator; set pressure per manual.

• Power & Communication: Wire power (12 VDC/AC) and Modbus/Ethernet for data transfer.

• Calibration: Load standard gas (±2% accuracy) and configure auto-calibration schedule.

ABB NGC8206 (2).jpg

Maintenance Tips

• Daily: Check carrier gas pressure and system status via controller display.

• Weekly: Verify calibration with standard gas and review historical data for drift.

• Monthly: Inspect sample filters and replace if clogged; clean oven vents.

• Quarterly: Service valves and flow regulators; update controller software if needed.

• Annually: Replace analytical module consumables (columns, detectors) and perform leak testing.
